The 2018-2019 Harley-Davidson Softail Fat Bob 114 is a rebellious, unapologetic beast that unleashes its full fury on the road. At the heart of this brawler lies the powerful Milwaukee-Eight engine, available in both 107 and 114 displacements, which channels its raw energy through a revised transmission and ESPFI fuel system.
The Softail frame has been overhauled to be lighter and stiffer, while the updated suspension – featuring inverted forks and an external rear preload adjustment – works in harmony with the new Showa SDBV suspension technology to deliver razor-sharp handling and an unflappable ride. The 2-1-2 upswept exhaust roars its approval as you carve through corners.
With a commanding presence, premium finishes, and your choice of engine displacement, the Fat Bob is ready to take on the world. Whether you’re cruising or carving up twisties, this bike’s unbridled performance and attitude will leave you breathless – and begging for more.
Key Specifications
Engine Type
Four stroke, V-Twin, 2 Milwaukee-Eight 114, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Engine Capacity
113.9 cubic inches / 1868 cc
Max Torque
114.3 ft-lb / 155 nm
Fuel Tank Capacity
13.6 Litres / US 3.6 gal
Weight (Wet/Kerb)
674.6 lbs / 306 kg
Seat Height
27.9 inches / 710 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson Softail Fat Bob 114
Year
2018 – 2019
Engine
Engine Type
Four stroke, V-Twin, 2 Milwaukee-Eight 114, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Displacement
113.9 cubic inches / 1868 cc
Bore x Stroke
102 x114.3 mm
Compression Ratio
10.5:1
Max Torque
114.3 ft-lb / 155 nm
Engine Management System
Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
