Harley Davidson Softail Deluxe (2018 – 2019)

Harley Davidson Softail Deluxe (2018 - 2019)

The Harley-Davidson Softail Deluxe has always been the epitome of style and luxury on two wheels. Now, beneath its sleek chrome exterior lies a modern powerhouse, boasting impressive advancements in technology and design.

With an astonishing 31-pound weight reduction, this cruiser offers effortless handling, unleashing massive power and acceleration from its Milwaukee-Eight 107 V-Twin engine. The ride is further elevated by the all-day comfort of its new seat and pullback handlebars, expertly designed for ease and control.

But it’s not just about raw performance – the Softail Deluxe also boasts retro-modern styled LED lighting, chrome laced wheels with whitewall tires, and a nostalgic boulevard look that turns heads. Experience the thrill of riding a seriously modern machine that stays true to its Harley-Davidson roots.

Key Specifications

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Engine Capacity1746 cc / 107 cub in
Max Torque148 Nm / 109 ft-lb @ 3000 rpm
Fuel Tank Capacity5 US gallons / 18.9 L
Weight (Wet/Kerb)696.6 lbs / 316 kg
Seat Height26.7 inches / 680 mm
Harley Davidson Softail Deluxe (2018 - 2019)

All Specifications

Make & Model

ModelHarley Davidson Softail Deluxe
Year2018 – 2019

Engine

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Displacement1746 cc / 107 cub in
Bore x Stroke100 x 111 mm
Compression Ratio10.0:1
Max Torque148 Nm / 109 ft-lb @ 3000 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Lubrication SystemPressurized, dry-sump with oil cooler
Cooling SystemAir cooled
Exhaust2-into-2 shorty dual, catalyst in muffler

Performance

Top Speedn/a

Transmission

ClutchMulti-plate, wet
Gearbox6 Speed
Gear Ratios1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.79:1
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Front SuspensionShowa Inverted forks
Rear SuspensionMono Shock adjustable
Rake30
Trail145 mm / 5.7 in

Wheels & Brakes

WheelsChrome Steel Laced
Front Tire SizeMT90B16 72H
Rear Tire SizeMU85B16 77H
Front Brakes2 x Disc, 4 piston caliper
Rear BrakesSingle Disc, 2 piston floating caliper

Dimension & Weights

Overall Length2415mm / 95 in
Seat Height26.7 inches / 680 mm
Wheelbase64.2 inches / 1630 mm
Ground Clearance115 mm / 4.5 in
Fuel Tank Capacity5 US gallons / 18.9 L
Wet (kerb/curb) Weight696.6 lbs / 316 kg
Dry Weight303 kg / 668 lbs

Features

  • 31lb lighter design
  • Milwaukee-Eight 107 V-Twin engine
  • Easier handling
  • Massive power and acceleration
  • All-day comfort from new seat
  • Pullback handlebars with chrome riser
  • Chrome laced wheels with whitewall tires
  • Retro-modern styled LED lighting
  • LED headlight, running lights, turn signals, and Tombstone tail/stop light
  • New softail frame design
  • Lighter and stiffer than previous models
  • High performance front suspension from Showa SDBV
  • High performance rear mono shock with dynamic cornering capability
  • Adjustable rear suspension for customized ride
