Harley Davidson Softail Breakout 114 (2020 – 2021)

Harley Davidson Softail Breakout 114 (2020 - 2021)

The Harley-Davidson Softail Breakout 114 is a masterclass in modern muscle, marrying the raw power of its Milwaukee-Eight 114 engine with sleek, custom lines that demand attention. This potent V-twin unleashes massive torque to the rear wheel, propelling you forward with authority and precision.

As you fire up the beast, the sweet rumble of the engine will leave onlookers in awe, while the responsive Softail frame and suspension deliver a thrilling ride experience that’s both agile and composed. Whether carving through twisties or blasting down the highway, every turn is an invitation to push your limits.

But it’s not just about raw power – the Breakout 114 also boasts sophisticated digital instrumentation, mounted high on risers for optimal visibility, and a sleek top fuel tank that accentuates its muscular engine. With loads of torque at your fingertips, you’ll be hard-pressed to resist the urge to put this beauty into overdrive, where it will reward you with thrilling acceleration and an unforgettable riding experience.

Key Specifications

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 114, pushrod-operated, overhead valves with hydraulic self-adjusting lifters, 4 valves per cylinder
Engine Capacity113.9 cubic inches / 1868 cc
Max Torque114.3 ft-lb / 155 nm
Fuel Tank Capacity3.5 US gallons / 13.2 L
Seat Height26.2 inches / 665 mm
Harley Davidson Softail Breakout 114 (2020 - 2021)

All Specifications

Make & Model

ModelHarley Davidson Softail Breakout 114
Year2020 – 2021

Engine

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 114, pushrod-operated, overhead valves with hydraulic self-adjusting lifters, 4 valves per cylinder
Displacement113.9 cubic inches / 1868 cc
Bore x Stroke102 x114 mm
Compression Ratio10.5:1
Max Torque114.3 ft-lb / 155 nm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Lubrication SystemPressurized, dry-sump with oil cooler
Cooling SystemAir cooled
Exhaust2-into-2 staggered; catalyst in muffler

Performance

Top Speedn/a

Transmission

ClutchMechanical, 10 plate wet, assist & conventional
Gearbox6 Speed
Gear Ratios1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.79
Final DriveBelt, 32/66 ratio

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, tubular frame, rectangular section backbone, stamped, cast, and forged junctions, MIG welded, aluminum forged fender supports
Front SuspensionShowa Inverted cartridge fork
Rear SuspensionMono Shock
Rake34
Trail145 mm / 5.7 in
SwingarmMild steel, tubular sections, stamped x-member, forged axle junctions, MIG welded, removable belt spacer

Wheels & Brakes

WheelsGloss black, Gasser II cast aluminum
Front Tire Size130/60B21,63H,BW
Rear Tire Size240/40R18,79V,BW
Front BrakesSingle 300 mm disc, 4 piston fixed caliper
Rear BrakesSingle 292 mm disc, 2 piston floating caliper

Dimension & Weights

Overall Length2370 mm / 93.3 in
Seat Height26.2 inches / 665 mm
Wheelbase66.7 inches / 1695 mm
Ground Clearance115 mm / 4.5 in
Fuel Tank Capacity3.5 US gallons / 13.2 L
Dry Weight294 kg / 648 lbs

Features

  • Milwaukee-Eight 114 engine
  • Massive torque to 240mm rear tire
  • Custom details from fender to fender
  • Re-invented Softail frame
  • Reinvented Softail suspension
  • Wide digital instrumentation
  • Speed readout
  • Fuel gauge
  • Gear indicator
  • Smooth top fuel tank
  • Lightweight design and stiffness of the frame
  • Racing-style cartridge fork suspension
  • Linear damping characteristics
  • Easily adjustable mono-shock rear suspension
  • Dynamic cornering capabilities
  • Quick acceleration and braking capabilities
Harley Davidson Softail Breakout 114 (2020 - 2021)
Harley Davidson Softail Breakout 114 (2020 - 2021)
Harley Davidson Softail Breakout 114 (2020 - 2021)
Harley Davidson Softail Breakout 114 (2020 - 2021)
Harley Davidson Softail Breakout 114 (2020 - 2021)
