Harley Davidson Road King Special 114 (2019 - 2020)

The 2019-2020 Harley-Davidson Road King Special is a force to be reckoned with, boasting a commanding presence on the road.

Mini-apex handlebars invite you to sit taller and ride more aggressively, while the Milwaukee-Eight 114 Engine unleashes a torrent of passing power and horizon-chasing authority. This is the most displacement in standard H-D Touring models, delivering 114 cubic inches of raw muscle at your command.

The Road King Special’s blacked-out custom styling strips away excess, revealing an aggressive, stripped-down machine that exudes power from every detail – from the turbine wheels to the tapered mufflers. Stretched saddlebags provide ample storage and a sleek look, while 19-inch Custom Black Turbine Wheels add a touch of head-turning style.

With its commanding big-bike presence, High-Performing front and rear suspension, and Reflex Linked Brembo Brakes with Standard ABS, this bike puts you firmly in control. And no matter how good you are, the Road King Special’s technology will make you an even better rider, ready to tackle any road condition with confidence.

Key Specifications

Engine Type	Four stroke, V-Twin, Milwaukee-Eight 114, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Engine Capacity	1868 cc / 114 cu in
Max Torque	122 ft-lb / 167 nm
Fuel Tank Capacity	6.0 US gallons / 22.7 L
Weight (Wet/Kerb)	820 lbs / 372 kg
Seat Height	26.4 inches / 668 mm

*n/a – information not provided by manufacturer

Harley Davidson Road King Special 114 (2019 - 2020)

All Specifications

Make & Model

Model	Harley Davidson Road King Special 114
Year	2019 – 2020

Engine

Engine Type	Four stroke, V-Twin, Milwaukee-Eight 114, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Displacement	1868 cc / 114 cu in
Bore x Stroke	102 x 114 mm
Compression Ratio	10.5:1
Max Torque	122 ft-lb / 167 nm
Engine Management System	Electronic Sequential Port Fuel Injection (ESPFI)
Lubrication System	Pressurized, dry-sump with oil cooler
Cooling System	Air cooled
Exhaust	Black, 2-1-2 dual exhaust with tapered mufflers

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Hydraulically actuated 9 plate wet, Assist & Slip
Gearbox	6 Speed
Gear Ratios	1st 9.593 2nd 6.65 3rd 4.938 4th 4 5th 3.407 6th 2.875
Final Drive	Belt

Electrical & Electronics System

Starter	Electric
ABS	Standard

Chassis & Suspension

Frame Type	Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded Swingarm Mild steel; two-piece drawn and welded section; forged junctions; MIG welded
Front Suspension	49 mm forks, Dual Bending Valve
Front Suspension Travel	4.6 inches / 117 mm
Rear Suspension	Premium low height hand-adjustable rear shocks
Rear Suspension Travel	2.15 inches / 54.6 mm
Rake	26
Trail	170 mm / 6.9 in

Wheels & Brakes

Wheels	Black, Turbine Cast Aluminium
Front Wheel/Rim Size	Black, Turbine Cast Aluminum
Front Tire Size	130/60B19 61H
Rear Wheel/Rim Size	Black, Turbine Cast Aluminum
Rear Tire Size	180/55B18 80H
Front Brakes	2 x 300 mm disc, caliper type 32 mm, 4-piston fixed, dual floating rotors
Rear Brakes	Single 300 mm, caliper type 32 mm, 4-piston, fixed rotor
ABS	Standard

Dimension & Weights

Seat Height	26.4 inches / 668 mm
Wheelbase	64 inches / 1625 mm
Ground Clearance	135 mm / 5.3 in
Fuel Tank Capacity	6.0 US gallons / 22.7 L
Wet (kerb/curb) Weight	820 lbs / 372 kg
Dry Weight	355 kg/ 785.6 lbs

Features

Mini-ape handlebars
9-inch tall, 1.25-inch wide handlebars
Milwaukee-Eight 114 Engine
114 cubic inches of displacement
Blacked-Out Custom Styling
Aggressive turbine wheels
Tapered mufflers
Stretched saddlebags
Single-touch opening lids
Custom Black Turbine Wheels
19-inch front wheels
18-inch rear wheels
Black Headlight Nacelle
Matching Trim Ring
High-performing front and rear suspension
Hand-adjustable rear shocks
Reflex Linked Brembo Brakes
Standard ABS

*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
