The Harley-Davidson FXSTSB Bad Boy is a rebellious take on the classic Springer design, inspired by the black-and-white era of 1940s cinema. With its stripped-back aesthetic, the Bad Boy trades chrome for a sleek, black finish that exudes an air of sophistication and power.
The bike’s engine, a potent V-twin powerhouse, delivers the kind of raw energy and character that defines the Harley-Davidson experience. From the responsive throttle to the rich, throaty exhaust note, every twist of the wrist is met with a satisfying growl that seems to reverberate deep within your very being.
When you swing onto the Bad Boy’s deeply-stepped saddle, you’re immediately enveloped in a classic sit-up-and-beg riding position that puts you firmly in control. With its shorter seat height and forward-mount foot controls, this bike is all about attitude and swagger – and it delivers on both counts.
The result is an unapologetically rugged yet refined motorcycle that’s as much at home carving up the boulevard as it is devouring the open road with reckless abandon. The Bad Boy is more than just a bike – it’s an experience, an attitude, and a way of life.
Key Specifications
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity
81.5 cubic inches / 1337 cc
Max Power
58 hp / 42.3 kW @ 5000 rpm
Max Torque
90.8 Nm / 67 lb.-ft. @ 3600 rpm
Fuel Tank Capacity
4.2 US gallons / 15.9 L
Seat Height
25.0 inches / 637 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson FXSTSB Bad Boy
Year
1995 – 96
Engine
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement
81.5 cubic inches / 1337 cc
Bore x Stroke
88.8 x 108.0 mm
Compression Ratio
8.5:1
Max Horsepower
58 hp / 42.3 kW @ 5000 rpm
Max Torque
90.8 Nm / 67 lb.-ft. @ 3600 rpm
Engine Management System
40mm Keihin CV carburetor
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Belt
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
39mm stanchions
Front Suspension Travel
6.9 inches / 175 mm
Rear Suspension
Dual dampers, able for preload
Wheels & Brakes
Front Tire Size
100/90-19
Rear Tire Size
130/90 HB16
Front Brakes
2x 292mm discs 1 piston caliper
Rear Brakes
Single 292mm disc
Dimension & Weights
Seat Height
25.0 inches / 637 mm
Fuel Tank Capacity
4.2 US gallons / 15.9 L
Dry Weight
281 kg / 320 lbs
Features
4.2-gallon fuel tank
Smaller seat height (25.75 inches in 1996)
Studded, deeply-stepped saddle
Forward-mount foot controls
Classic sit-up-and-beg posture
Slotted disc rear wheel (like the Custom)
Electronic speedometer (added in 1996)
Black paint and chrome accents
Available in black only (except for tank and fender graphics colors)
Seat height 1 inch lower than Sportster Hugger
Lost 5 pounds compared to predecessor
Revised Softail chassis geometry for more rear wheel travel
Quieter, smoother-shifting gearbox
Slotted floating disc brakes
