Harley Davidson FXSTS-SE2 Screamin’ Eagle Softail Springer (2008)

Harley Davidson FXSTS-SE2 Screamin' Eagle Softail Springer (2008)

The 2008 FXSTS-SE2 Screamin’ Eagle Softail Springer is a masterclass in blending modern performance with nostalgic style.

This stunning motorcycle boasts an impressive array of premium components, including chrome leading-link fork, color-matched rigid leg, and horizontal-mounted coil-over suspension. The engine at its heart is the mighty Twin Cam 110B, a powerhouse that delivers exceptional torque and acceleration. As you ride, the Screamin’ Eagle Softail Springer exudes a sense of raw power and unbridled freedom.

Rounding out this stunning package are dazzling colors, including the serialized 105th Anniversary combination with gold leaf graphics, and an abundance of chrome accents throughout. The result is a motorcycle that’s as much a work of art as it is a thrilling ride, commanding attention wherever you go.

The 2008 FXSTS-SE2 Screamin’ Eagle Softail Springer truly lives up to its name: this is a bike that screams with power and style, an unforgettable riding experience that will leave you breathless.

Key Specifications

Engine TypeFour stroke, Twin Cam 110 Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Engine Capacity1804 cc / 110.1 cub in.
Max Torque149 Nm / 110 ft lbs @ 3000 rpm
Fuel Tank Capacity5.0 US gallons / 9.0 L
Weight (Wet/Kerb)724 lbs / 328 kg
Seat Height24.7 inches / 627.4 mm
Harley Davidson FXSTS-SE2 Screamin' Eagle Softail Springer (2008)

All Specifications

Make & Model

ModelHarley Davidson FXSTS-SE2 Screamin’ Eagle Softail Springer
Year2008

Engine

Engine TypeFour stroke, Twin Cam 110 Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Displacement1804 cc / 110.1 cub in.
Bore x Stroke101.6 x 111.3 mm
Compression Ratio9.3:1
Max Torque149 Nm / 110 ft lbs @ 3000 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Cooling SystemAir cooled

Performance

Top Speedn/a

Transmission

ClutchMulti-plate, wet
Gearbox6 Speed
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel tubular frame; rectangular section backbone; stamped, cast and forged junctions; forged fender supports; MIG welded; color-matched to vehicle Swingarm Mild steel, tube sections, stamped junctions; MIG welded; painted,
Front SuspensionChrome leading-link fork; color-matched rigid leg
Rear SuspensionHidden, horizontal-mounted, coil-over Wheels4 Chrome, 10-spoke Forged Aluminum
Rake32
Trail134 mm / 5.3 in

Wheels & Brakes

Front Tire SizeMH90-21 54H
Rear Tire Size200/55R17 78V
Front Brakes2x 292mm disc 4 piston caliper
Rear BrakesSingle 292mm disc 4 piston caliper

Dimension & Weights

Seat Height24.7 inches / 627.4 mm
Wheelbase65.4 inches / 1661.2 mm
Ground Clearance130 mm / 5.1 in
Fuel Tank Capacity5.0 US gallons / 9.0 L
Wet (kerb/curb) Weight724 lbs / 328 kg
Dry Weight315 kg / 694 lbs

Features

  • Chrome leading-link fork
  • Color-matched rigid leg
  • Hidden, horizontal-mounted, coil-over shocks
  • Wheels: 10-spoke Forged Aluminum, chrome
  • Twin Cam 110B engine
  • High-performance V-Twin engine
  • Largest-displacement production engine offered by Harley-Davidson
  • Granite and Chrome treatment on the engine
  • Electronic Sequential Port Fuel Injection (ESPFI)
  • Standard ESPFI is standard on the Twin Cam 110B
  • Chrome shotgun exhaust
  • Heavy Breather intake with special “110” end cap
  • High flow, forward facing exposed Heavy Breather intake
  • Reduced reach front brake lever for optimal ergonomics
  • Braided cables and lines
  • Color-matched frame inserts
  • Chrome rear axle nut covers
  • 18 x 3.5-inch chrome Revolver front wheel
  • 130 mm, 18-inch front tire
