The Harley-Davidson FXRS 1340 Low Rider was a high-performance variant of the iconic Softail model line introduced in 1986. This sleek and powerful bike boasted a V-twin engine, displacing 1,340cc, with dual carburetors and an air-cooled design.
The engine’s character is unmistakable – a robust, throaty growl and impressive torque delivery that propels the rider forward with ease. Its wide handlebars and low-slung riding position invite aggressive handling, while its suspension system provides ample comfort for long-distance travel.
As you settle into the Low Rider’s saddle, the real-world power delivery is an experience in itself – each gear a delight to explore, as torque seamlessly integrates acceleration and braking forces. The ultimate rider experience lies in this perfect blend of power, style, and control that redefined the boundaries of what was possible on two wheels, forever leaving its mark on the motorcycle world with its unique blend of brawn and beauty.
Key Specifications
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity
81.5 cubic inches / 1337 cc
Max Power
58 hp / 42.3 kW @ 5000 rpm
Max Torque
90.8 Nm / 67 lb.-ft. @ 3600 rpm
Fuel Tank Capacity
4.2 US gallons / 16.0 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson FXRS 1340 Low Rider
Year
1986 – 92
Engine
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement
81.5 cubic inches / 1337 cc
Bore x Stroke
88.8 x 108.0 mm
Compression Ratio
8.5:1
Max Horsepower
58 hp / 42.3 kW @ 5000 rpm
Max Torque
90.8 Nm / 67 lb.-ft. @ 3600 rpm
Engine Management System
38mm Keihin carburetor
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Belt
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
38mm Telescopic air assistance, 175mm wheel travel.
*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
