The Harley-Davidson FXRDG 1340 Disc Glide is a true factory-built custom, where every detail has been carefully crafted to create an unparalleled riding experience. Its sleek design boasts a distinctive rear wheel disc, paired with a wire-spoke front wheel, giving it a unique visual presence on the road.
Under the hood lies the legendary 80-inch V-twin engine, renowned for its raw power and character. As you twist the throttle, the Disc Glide comes alive, delivering a thrilling ride that’s as much about the journey as the destination. Its low-slung seat and rake-forward design make it perfect for carving up tight turns and navigating twisty roads.
With an MSRP of $8199, this exclusive model is not for the faint of heart – or wallet. But for those who crave something truly special, the Disc Glide offers a level of exclusivity that’s hard to find elsewhere. And with its small-batch production run, it’s likely one of these unique machines will soon become your own private treasure.
Key Specifications
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity
81.5 cubic inches / 1337 cc
Max Power
59 hp / 44 kW @ 5500 rpm
Max Torque
90.8 Nm / 67 lb.-ft. @ 3600 rpm
Fuel Tank Capacity
4.2 US gallons / 16.0 L
Weight (Wet/Kerb)
272 kg /
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson FXRDG 1340 Disc Glide
Year
1984
Engine
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement
81.5 cubic inches / 1337 cc
Bore x Stroke
88.8 x 108.0 mm
Compression Ratio
8.5:1
Max Horsepower
59 hp / 44 kW @ 5500 rpm
Max Torque
90.8 Nm / 67 lb.-ft. @ 3600 rpm
Engine Management System
Carburetor
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Belt
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Wheels & Brakes
Front Tire Size
M/90-19
Rear Tire Size
M/90-16
Front Brakes
Single 292mm disc
Rear Brakes
Single 292mm disc
Dimension & Weights
Fuel Tank Capacity
4.2 US gallons / 16.0 L
Wet (kerb/curb) Weight
272 kg /
Features
Rear wheel disc brake
Wire-spoke front wheel
Cast wheels on FXRS and FXRT models
Composite disc wheel construction
Aluminum halves joined by rivets
0.160-inch aluminum used in disc wheel
No functional advantage over cast wheel
Requires tube in rear tire with disc wheel
Disc wheel weighs 2 pounds more than standard FXRS cast piece (15 pounds)
Chrome-plated aluminum engine covers
Engine covers polished to perfection for chroming process
Expensive and difficult process of chrome plating on aluminum
Polishing and monitoring chemicals involved in chrome plating
Limited production run of approximately 860 units
Available only with evaporative control system (ECS) compliant since January 1, 1984
California models not available due to ECS regulations
