Cruising down the highway on a Harley-Davidson vee-twin is an experience like no other. The sheer presence of the engine thunders through every fiber of your being as it churns along at a relaxed 3,250 rpm. It’s a sensory overload that’s both exhilarating and intimidating.
The FXE-1200 Super Glide is the epitome of this raw power and unbridled freedom. Its 45-degree vee-twin engine, the same one that powers the iconic FLH1200 Electra-Glide tourer, is a force to be reckoned with. And yet, it’s not just about brute strength – the Super Glide has a lean and mean demeanor that’s hard to ignore.
As you settle into its deep saddle, you’ll feel an instant connection to the bike. The controls seem miles away, but in reality, they’re just out of reach. It’s a subtle hint at the unique riding experience that awaits. You won’t be “riding” this bike – you’ll be sitting in it, feeling every rumble and vibration as you devour the road ahead.
And then there’s the looks. The western droop ‘bars, 2J-gallon tank, banana seat, and abbreviated fenders all combine to create a machine that’s equal parts rough-around-the-edges charm and unapologetic attitude. This is a bike that doesn’t care what you think – it’s here to be ridden hard and put away wet.
In the world of motorcycles, there’s no denying that the Harley-Davidson FXE-1200 Super Glide is an acquired taste.
Key Specifications
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity
73.5 cubic inches / 1207 cc
Max Power
65 hp @ 5500 rpm
Max Torque
NA
Fuel Tank Capacity
3.3 US gallons / 12.5 L
Weight (Wet/Kerb)
606.3 lbs / 275.0 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson FXE 1200 Super Glide
Year
1974 – 77
Engine
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement
73.5 cubic inches / 1207 cc
Bore x Stroke
87.3 x 100.8 mm
Compression Ratio
8.0:1
Max Horsepower
65 hp @ 5500 rpm
Max Torque
NA
Engine Management System
Single 38mm Keihin carburetor
Cooling System
Air cooled
Performance
Top Speed
108 mph
*n/a – information not provided by manufacturer
Transmission
Gearbox
4 Speed
Gear Ratios
1st 10-25 / 2nd 6-24 / 3rd 4-21 / 4th 3-42 to 1
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
Telescopic forks, 89mm wheel travel
Rear Suspension
Swinging fork. Duplex loop cradle with cast lugs.
Wheels & Brakes
Front Tire Size
3.25-19
Rear Tire Size
5.10-16
Front Brakes
Single 298mm disc
Rear Brakes
Single 248mm disc
Dimension & Weights
Fuel Tank Capacity
3.3 US gallons / 12.5 L
Wet (kerb/curb) Weight
606.3 lbs / 275.0 kg
Features
Deep saddle at axle height
Controls located 3 ft above saddle
Electric starter as standard equipment (FXE-1200 model)
45-degree vee-twin engine
12-hundred cc engine capacity
Maximum power output: around 65 bhp at 5,500 rpm
Exhaust system with latest style exhaust note and effective sound reduction
Severely reduced performance due to exhaust system
Maximum speed: 108 mph (two-way mean)
Best run speed: almost 114 mph
Standing quarter-mile time: 15.3 seconds
Weight: 585 lb with a gallon of fuel
Leaner and more esoteric design compared to other Harley-Davidson models
