Harley Davidson FXD/I Dyna Super Glide (2003 – 2005)

The Harley-Davidson FXD/I Dyna Super Glide is a bike that embodies the perfect blend of sporty style and custom attitude. Its Twin Cam 88 engine, nestled low in a vibration-damping frame, churns out an abundance of torque to put a grin on your face.

Underneath you, the XR-style flat track handlebar gives you a more aggressive stance and performance-oriented feel, while the 28-degree front-end with dual rate springs delivers nimble handling that’s as responsive as it is fun. The Fat Bob tank, center console, and top-mount speedometer only add to the overall sense of dynamism.

From its standard two-up seat to its stepped, performance-minded design, every detail on this bike screams ‘ride me.

Key Specifications

Engine Type	Four stroke, 45 V-Twin,Twin Cam 88 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Engine Capacity	88.4 cubic inches / 1449 cc
Max Power	67 hp / 48.8 kW @ 5200 rpm
Max Torque	86 ft-lb / 116.6 nm
Fuel Tank Capacity	4.8 US gallons / 18.6 L
Weight (Wet/Kerb)	663 lbs / 301 kg
Seat Height	26.6 inches / 675.6 mm

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Harley Davidson FXD/I Dyna Super Glide
Year	2003 – 2005

Engine

Engine Type	Four stroke, 45 V-Twin,Twin Cam 88 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Displacement	88.4 cubic inches / 1449 cc
Bore x Stroke	95.3 x 101.6 mm
Compression Ratio	8.9:1
Max Horsepower	67 hp / 48.8 kW @ 5200 rpm
Max Torque	86 ft-lb / 116.6 nm
Engine Management System	Carburetion 40 mm constant velocity with enrichener and accelerator pumpESPFI 38 mm throttle bore electronic sequential port fuel injection
Lubrication System	Dry sump, internally mounted, crank driven gerotor pressure and dual scavenge pump with spin on 10 pressurized oil filter
Cooling System	Air cooled

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Wet 9-plate
Gearbox	5 Speed
Gear Ratios	1st 10.1102nd 6.9583rd 4.9534th 3.8625th 3.150
Final Drive	Belt

Electrical & Electronics System

Starter

Electric

Chassis & Suspension

Frame Type	Mild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded
Front Suspension	39 mm w/ polished aluminum fork triple clamp and dual-rate springs
Rear Suspension	Coil over shock
Rake	29
Trail	120 mm / 4.7 in

Wheels & Brakes

Front Tire Size	100/90-19
Rear Tire Size	MT90 B16
Front Brakes	Single 292mm disc 4 piston calipers
Rear Brakes	Single 292mm disc 4 piston calipers

Dimension & Weights

Seat Height	26.6 inches / 675.6 mm
Wheelbase	64.2 inches / 1630.0 mm
Ground Clearance	153 mm / 6.0 in
Fuel Tank Capacity	4.8 US gallons / 18.6 L
Wet (kerb/curb) Weight	663 lbs / 301 kg
Dry Weight	287 kg / 632.2 lbs

Features

Carburetion 40 mm constant velocity with enrichener and accelerator pump
ESPFI 38 mm throttle bore electronic sequential port fuel injection
Twin Cam 88 engine with torque
XR-style flat track handlebar for aggressive stance and performance-minded look
28-degree front-end with dual rate springs for responsive handling
Fat Bob tank for increased fuel capacity
Center console with controls
Top-mount speedometer
Stepped, two-up seat for passenger comfort
Vibration-isolated engine mount
Opportunities for individual customization and performance upgrades
Laced wheel option available
Security System as an option
Electronic Fuel Injection (EFI) available
