Harley Davidson FXCWC Softail Rocker C (2010)

Harley Davidson FXCWC Softail Rocker C (2010)

The 2010 Harley-Davidson FXCWC Softail Rocker C is a masterclass in stripped-back style and substance. Its sleek design features a chromed-out aesthetic, complete with brilliant chrome plating on the headlamp, triple clamps, handlebar riser, fork lowers, tank console, and speedometer.

At its heart lies a 1584cc Twin Cam 96B balanced engine, delivering raw power through a 6-speed Cruise Drive transmission. The engine is dressed in black powdercoat with chrome covers, while Shorty Dual mufflers add to the bike’s menacing presence.

Hit the open road and you’ll be greeted by the distinctive rumble of this V-twin beast. As you carve through the twisties, the Rocker C’s rigid-mount engine and 240 mm-18 rear tire provide a planted and confident ride. With its polished Cast Aluminum Tapered Five Spoke wheels and color-matched frame, swingarm, and oil tank, this bike exudes an unmistakable air of sophistication.

But don’t be fooled – the Rocker C is a chopper at heart, with all the attitude and swagger that comes with it. Whether you’re cruising down Main Street or carving up the open road, the Harley-Davidson FXCWC Softail Rocker C is a bike that demands to be ridden hard, and loved forever.

Key Specifications

Engine TypeFour stroke, 45 V-Twin,Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Engine Capacity96 cubic inches / 1584 cc
Max Torque124.7 Nm / 92 ft. lbs @ 3000 rpm
Fuel Tank Capacity5.0 US gallons / 9.0 L
Weight (Wet/Kerb)716.9 lbs / 325.1 kg
Seat Height25.2 inches / 640.08 mm
Harley Davidson FXCWC Softail Rocker C (2010)

All Specifications

Make & Model

ModelHarley Davidson FXCWC Softail Rocker C
Year2010

Engine

Engine TypeFour stroke, 45 V-Twin,Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Displacement96 cubic inches / 1584 cc
Bore x Stroke95.2 x 111.2 mm
Compression Ratio9.2:1
Max Torque124.7 Nm / 92 ft. lbs @ 3000 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Cooling SystemAir cooled

Performance

Top Speedn/a

Transmission

Gearbox6 Speed
Gear Ratios1st 9.312 9.312 9.0302nd 6.421 6.421 6.2263rd 4.774 4.774 4.6304th 3.926 3.926 3.8075th 3.279 3.279 3.1796th 2.790 2.790 2.706
Final DriveBelt

Electrical & Electronics System

Chassis & Suspension

Frame TypeMild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded Swing Arm Mild steel, elliptical tube sections, forged junctions; MIG welded
Front Suspension49mm telescopic forks
Front Suspension Travel5.0 inches / 127 mm
Rear SuspensionHidden, horizontal-mounted, coil-over
Rear Suspension Travel3.3 inches / 86.3 mm
Rake36.5
Trail157.4 mm / 6.2 in

Wheels & Brakes

Front Tire SizeD407 90/90-19
Rear Tire SizeD407 240/40R18
Front BrakesSingle 292mm disc 4 piston caliper
Rear BrakesSingle 292mm disc 2 piston caliper

Dimension & Weights

Seat Height25.2 inches / 640.08 mm
Wheelbase69.2 inches / 1757.68 mm
Ground Clearance130 mm / 5.1 in
Fuel Tank Capacity5.0 US gallons / 9.0 L
Wet (kerb/curb) Weight716.9 lbs / 325.1 kg

Features

  • Electronic Sequential Port Fuel Injection (ESPFI)
  • Rigid-mount, 1584cc Twin Cam 96B balanced engine
  • 6-speed Cruise Drive transmission
  • Black powdercoated engine with chrome covers
  • Chrome Shorty Dual mufflers with slash-cut outlets
  • Finned cast-aluminum oil tank
  • 240 mm-18 rear / 90 mm-19 front tire
  • Polished Cast Aluminum Tapered Five Spoke 19-inch front/18-inch rear wheels
  • Rockertail rear section
  • Stretched fuel tank with recessed cloisonn medallion
  • Trick seat with concealed passenger pillion
  • Independent V-Bar handlebars on five-inch curved risers
  • Console-mounted speed shop style speedometer
  • Color-matched frame, swingarm and oil tank
  • Chrome fork lowers, headlamp, console, speedometer and other components
  • Integrated LED rear turn indicators/tail/brake lamps
