The Harley-Davidson FLTR Road Glide is a powerhouse of style and performance, devouring the highway with its sleek shark nose frame-mounted fairing. At the heart of this machine lies the 1584cc Twin Cam 96 engine, delivering a deep rumble as it unleashes its raw power through the 6-speed Cruise Drive transmission.
The ride experience is nothing short of exhilarating, with the Road Glide’s Brembo triple-disc brake system and six-gallon fuel tank providing ample control and range. Whether cruising or carving through twisties, the new chassis delivers precise responsive maneuverability, increased capacity, and greater comfort for both rider and passenger.
With its advanced features like electronic throttle control, GPS, and a 40-watt Advanced Audio System by Harman/Kardon, this Touring bike is the epitome of modern motorcycling.
Key Specifications
Engine Type
Four stroke, 45 V-Twin,Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Engine Capacity
96 cubic inches / 1584 cc
Max Torque
124.7 Nm / 92 ft. lbs @ 3000 rpm
Fuel Tank Capacity
5 US gallons / 9.0 L
Weight (Wet/Kerb)
789 lbs / 357.8 kg
Seat Height
26.9 inches / 683.3 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson FLTR Road Glide
Year
2009
Engine
Engine Type
Four stroke, 45 V-Twin,Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Displacement
96 cubic inches / 1584 cc
Bore x Stroke
95.2 x 111.2 mm
Compression Ratio
9.2:1
Max Torque
124.7 Nm / 92 ft. lbs @ 3000 rpm
Engine Management System
Electronic Sequential Port Fuel Injection (ESPFI)
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
6 Speed
Final Drive
Belt
Electrical & Electronics System
Chassis & Suspension
Frame Type
Mild steel, square-section backbone with twin downtubes
Front Suspension
41.3 mm telescopic, cartridge-style damping
Rear Suspension
Short, air-adjustable shock
Rake
26
Trail
157.5 mm / 6.2 in
Wheels & Brakes
Front Tire Size
MT90B16
Rear Tire Size
MU85B16
Front Brakes
2x 292mm disc 4 piston caliper
Rear Brakes
Single 292mm disc 4 piston caliper
Dimension & Weights
Seat Height
26.9 inches / 683.3 mm
Wheelbase
63.5 inches / 1612.9 mm
Fuel Tank Capacity
5 US gallons / 9.0 L
Wet (kerb/curb) Weight
789 lbs / 357.8 kg
Dry Weight
341 kg / 752 lbs
Features
Electronic Sequential Port Fuel Injection (ESPFI)
Shark nose frame-mounted fairing
Hard-shell saddlebags
Electronic cruise control
Advanced Audio System by Harman/Kardon
Dual covered headlamps
Back-slash muffler tips
New graphics on fairing, fuel tank and saddlebags
Low-mount license bracket with new LED illumination
Rubber mounted 1584cc Twin Cam 96 engine
ESPFI transmission
Brembo triple-disc brake system
Six-gallon fuel tank
Electronic Throttle Control
NEW 2-1-2 exhaust system
Engine isolation system
Isolated Drive System
Frame and swingarm redesign
