The Harley-Davidson FLTR Road Glide – a behemoth of a bike that embodies the essence of American motorcycle culture. With its imposing presence and sleek design, this touring icon is not for the faint of heart. Powered by a robust V-twin engine, the FLTR exudes raw power and unbridled energy, its rumbling exhaust note an unmistakable declaration of its unwavering character.
Built to dominate the open road, the Road Glide boasts exceptional stability and agility, making it an ideal companion for long-distance adventures. Its ergonomic design ensures a comfortable riding position, while its generous storage capacity allows riders to carry everything they need on their journey.
For those seeking an unparalleled riding experience, the FLTR is a masterclass in performance and style. Whether carving through twisties or cruising down the highway, this Harley-Davidson behemoth demands attention and respect – and delivers it in spades. The FLTR Road Glide is not just a motorcycle – it’s an event waiting to happen, every time you fire up its engine.
Key Specifications
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity
81.5 cubic inches / 1337 cc
Max Power
67 hp / 48.9 kW @ 6000 rpm
Max Torque
71.5 ft-lb / 97 nm
Fuel Tank Capacity
18.9 Litres / US gal
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson FLTR Road Glide
Year
1996 – 98
Engine
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement
81.5 cubic inches / 1337 cc
Bore x Stroke
88.8 x 108 mm
Compression Ratio
8.5:1
Max Horsepower
67 hp / 48.9 kW @ 6000 rpm
Max Torque
71.5 ft-lb / 97 nm
Engine Management System
38mm Keihin carburetor
Lubrication System
Dry sump
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Dry, multiple discs, cable operated
Gearbox
5 Speed
Final Drive
Belt
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Steel, Double cradle frame
Front Suspension
41mm stanchions
Rear Suspension
Dual dampers
Wheels & Brakes
Front Tire Size
130/90-16
Rear Tire Size
130/90-16
Front Brakes
2x 292mm discs 4 piston calipers
Rear Brakes
Single 292mm disc 4 piston caliper
Dimension & Weights
Wheelbase
63.5 inches / 1613 mm
Ground Clearance
130 mm / 5.1 in
Fuel Tank Capacity
18.9 Litres / US gal
Dry Weight
344 kg / 758 lbs
Features
High-performance Screamin’ Eagle parts package
Big-bore cylinders
Flat-top pistons
Aggressive cams
Intake calibration cartridge
Air cleaner
$7,500 in Genuine Harley-Davidson custom accessories as standard equipment
Choice of two paint schemes with the Screamin’ Eagle logo on the front fairing
Limited edition model (only 1500 will be made)
Powertrain upgrades for increased horsepower and torque
Ten-percent increase in horsepower
Fourteen-percent gain in torque
Street-legal performance package
High-flow air filter
Vance and Hines pipes
Re-mapped ignition
Mikuni Smooth Bore carburetor
Big-bore kit
