The Harley-Davidson FLTR/I Road Glide is a tourer that redefines the boundaries of long-distance cruising. Powered by an all-new Twin Cam 88 engine, this road warrior boasts exceptional performance and handling capabilities.
The Twin Cam 88’s smooth power delivery and responsive acceleration make it an absolute delight to ride. Paired with the ESPFI electronic sequential port fuel injection system, this bike is a masterclass in engineering and design.
Whether you’re carving through twisties or cruising down the open road, the Road Glide’s exceptional ergonomics and comfort features ensure a fatigue-free riding experience. With its premium stereo sound system, weather band, digital clock, and intuitive handlebar controls, every aspect of this bike is designed to provide an unparalleled level of sophistication.
Experience the thrill of riding a machine that seamlessly blends power, style, and luxury – the Harley-Davidson FLTR/I Road Glide is truly in a league of its own.
Key Specifications
Engine Type
Four stroke, 45 V-Twin,Twin Cam 88 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Engine Capacity
88.4 cubic inches / 1449 cc
Max Power
67 hp / 48.8 kW @ 5200 rpm
Max Torque
86 ft-lb / 116.6 nm
Fuel Tank Capacity
5.0 US gallons / 19.0 L
Weight (Wet/Kerb)
811 lbs / 368 kg
Seat Height
27.3 inches / 693.4 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson FLTR/I Road Glide
Year
2001 – 2002
Engine
Engine Type
Four stroke, 45 V-Twin,Twin Cam 88 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Displacement
88.4 cubic inches / 1449 cc
Bore x Stroke
95.3 x 101.6 mm
Compression Ratio
8.9:1
Max Horsepower
67 hp / 48.8 kW @ 5200 rpm
Max Torque
86 ft-lb / 116.6 nm
Engine Management System
Carburetion 40 mm constant velocity with enrichener and accelerator pumpESPFI 38 mm throttle bore electronic sequential port fuel injection
Lubrication System
Dry sump, internally mounted, crank driven gerotor pressure and dual scavenge pump with spin on 10 pressurized oil filter
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet 9-plate
Gearbox
5 Speed
Final Drive
Belt
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
Air adjustable forks
Rear Suspension
Air adjustable shocks
Rake
26
Trail
157.5 mm / 6.2 in
Wheels & Brakes
Front Tire Size
D402F MT90B16 72H
Rear Tire Size
D402 MT90B16 74H
Front Brakes
2x 292mm discs 4 piston calipers
Rear Brakes
Single 292mm disc 4 piston caliper
Dimension & Weights
Seat Height
27.3 inches / 693.4 mm
Wheelbase
63.5 inches / 1612.9 mm
Ground Clearance
130 mm / 5.1 in
Fuel Tank Capacity
5.0 US gallons / 19.0 L
Wet (kerb/curb) Weight
811 lbs / 368 kg
Dry Weight
355 kg /776.0 lbs
Features
Chrome and wrinkle black Twin Cam 88 engine
Carbureted or fuel injected engine options (note: not available in all countries)
Frame-mounted fairing
Low windshield
Enclosed twin-oval reflector optic headlamp
“H-D” embossed seat and pillion
Distortion-free premium stereo sound system
AM/FM/Cassette radio with fairing-mounted speakers
Handlebar switches for music control
Wiring and switches for upgrading the ride
Clean-looking round gauge package with digital clock, radio controls, etc.
Custom solo saddle with removable passenger seat
Removable Lexan windshield
Fat Bob fuel tank
Adjustable rider and passenger footboards
Fiberglass saddlebags with chrome slant latches and attached lids
Integrated fork lock
Hazard warning flasher
5-gallon fuel tank
