Harley Davidson FLSTSE3 Softail Convertible CVO (2012)

Harley Davidson FLSTSE3 Softail Convertible CVO (2012)

The Harley-Davidson FLSTSE3 Softail Convertible CVO is a masterclass in adaptability, designed to seamlessly transition from touring machine to solo profiling bike. At the heart of this remarkable machine lies the 110ci (1800cc) V-Twin engine, its Electronic Sequential Port Fuel Injection (ESPFI) system delivering immense torque and character.

The rigid powertrain creates an unbreakable bond between rider and motorcycle, while the Softail rear suspension expertly balances vintage aesthetics with modern comfort. With a simple twist of a few screws, riders can transform their CVO into a two-up cruiser or solo touring bike, thanks to its innovative detachable components.

Whether navigating tight city streets or carving up open highways, the Harley-Davidson FLSTSE3 Softail Convertible CVO is an unparalleled riding experience. Its redesigned windshield slashes turbulence, and the integrated Road Tech zumo 660 GPS Navigator ensures navigation has never been easier.

Key Specifications

Engine TypeFour stroke, Twin Cam 110 Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Engine Capacity110 cubic inches / 1802 cc
Max Torque146 Nm / 107.7 ft. lbs @ 3000 rpm
Fuel Tank Capacity5.0 US gallons / 18.9 L
Weight (Wet/Kerb)756 lbs / 343 kg
Seat Height24.4 inches / 619.76 mm
Harley Davidson FLSTSE3 Softail Convertible CVO (2012)

All Specifications

Make & Model

ModelHarley Davidson FLSTSE3 Softail Convertible CVO
Year2012

Engine

Engine TypeFour stroke, Twin Cam 110 Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Displacement110 cubic inches / 1802 cc
Bore x Stroke101.6 x 111.25 mm
Compression Ratio9.6:1
Max Torque146 Nm / 107.7 ft. lbs @ 3000 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Cooling SystemAir cooled
ExhaustChrome, straight over / under shotgun, slash-cut with dual mufflers

Performance

Top Speedn/a

Transmission

Gearbox6 Speed
Gear Ratios1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.790
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; MIG welded; color-matched to vehicle
Front Suspension41.3 mm telescopic, chrome “beer can” covers
Rear SuspensionSwingarm Mild steel tube sections, forged junctions; MIG welded; color-matched to vehicle rear shocks Hidden, horizontal-mounted, coil-over
Rake32
Trail147 mm / 5.8 in

Wheels & Brakes

Front Tire Size130/70R18
Rear Tire Size200/50R18
Front BrakesSingle 292mm disc 4 piston caliper
Rear BrakesSingle 292mm disc 2 piston caliper

Dimension & Weights

Seat Height24.4 inches / 619.76 mm
Wheelbase64.2 inches / 1630.6 mm
Ground Clearance94 mm / 3.7 in
Fuel Tank Capacity5.0 US gallons / 18.9 L
Wet (kerb/curb) Weight756 lbs / 343 kg
Dry Weight328.41 kg / 724 lbs

Features

  • Electronic Sequential Port Fuel Injection (ESPFI) system
  • Twin Cam 110 V-Twin engine
  • Up to 122 ft. lbs. of torque
  • Detachable compact fairing
  • Saddlebags with distressed brown leather or black leather with reptile inserts
  • Passenger pillion and backrest
  • Redesigned windshield for reduced turbulence
  • Integrated Road Tech zumo 660 GPS Navigator with MP3 player
  • Two-speaker audio system
  • Turn-by-turn voice commands
  • Electronic cruise control
  • Keyless ignition
  • Anti-lock Braking System (ABS)
  • Softail rear suspension
  • Hidden modern suspension under the chassis
  • Rigid powertrain for solid connection to the rider and engine
