Harley Davidson FLSTF Fat Boy (2008)

The Harley-Davidson FLSTF Fat Boy is the embodiment of raw power and unbridled attitude, its aggressive stance and menacing presence on the road unmistakable. At its heart lies a 96ci Twin Cam engine, pumping out effortless torque and bellowing with a rich, throaty growl that’s music to any rider’s ears.

The FLSTF Fat Boy is built for those who crave an immersive riding experience, one where every twist of the wrist is met with immediate response from the bike. Its ESPFI fuel injection system delivers precise control over airflow, ensuring seamless transitions between gears and a silky-smooth ride that belies its formidable size.

This 2008 model boasts cutting-edge technology, including Harley-Davidson’s renowned Cruise Drive transmission and an array of premium components that speak to the company’s commitment to craftsmanship.

Key Specifications

Engine Type	Four stroke, Twin Cam 96BTM Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Engine Capacity	96 cubic inches / 1584 cc
Max Torque	124.7 Nm / 92 ft. lbs @ 3000 rpm
Fuel Tank Capacity	18.9 Litres / 5.0 gal
Weight (Wet/Kerb)	725 lbs / 329.0 kg
Seat Height	25.0 inches / 635 mm

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Harley Davidson FLSTF Fat Boy
Year	2008

Engine

Engine Type	Four stroke, Twin Cam 96BTM Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Displacement	96 cubic inches / 1584 cc
Bore x Stroke	95.25 x 111.25 mm
Compression Ratio	9.2:1
Max Torque	124.7 Nm / 92 ft. lbs @ 3000 rpm
Engine Management System	Electronic Sequential Port Fuel Injection (ESPFI)
Cooling System	Air cooled

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Multi-plate, wet
Gearbox	6 Speed
Gear Ratios	1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.790
Final Drive	Belt

Electrical & Electronics System

Starter

Electric

Chassis & Suspension

Frame Type	Mild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded
Front Suspension	41.3 mm telescopic, chrome dust covers
Rear Suspension	Hidden, horizontal-mounted, coil-over shock
Rake	31.6
Trail	147 mm / 5.7 in

Wheels & Brakes

Front Tire Size	140/75R17
Rear Tire Size	200/55R17
Front Brakes	Single 292mm disc 4 piston caliper
Rear Brakes	Single 292mm disc 4 piston caliper

Dimension & Weights

Seat Height	25.0 inches / 635 mm
Wheelbase	67.5 inches / 1715 mm
Fuel Tank Capacity	18.9 Litres / 5.0 gal
Wet (kerb/curb) Weight	725 lbs / 329.0 kg

Features

Electronic Sequential Port Fuel Injection (ESPFI)
All-new Rockertail rear section
Slimmed-down hardtail look
Hidden horizontal coil-over shock absorbers for the rear suspension
Counter-balanced Twin Cam 96B powertrain
Low seat height
Harley-Davidson ESPFI fuel injection standard on all Softails
6-speed Cruise Drive transmission standard on all Softails
Horseshoe-shaped oil tank located below the seat
Fuel tank-mounted console and ignition
Top-Mounted Battery with relocated terminal attachment points
Hollow Axles with new bearings, spacers, and sleeves
25 mm hollow axles stiffen the rear swingarm for a more stable feel
Solo saddle just 24.5 inches off the ground
Forward controls
Independent V-Bar handlebars
