The Harley-Davidson FLSTC/I Heritage Softail Classic embodies the essence of custom touring, marrying nostalgic style with modern performance. At its heart is the new Twin Cam 96B engine, a 1584cc powerhouse that delivers a rich, velvety smoothness to the riding experience.
Featuring ESPFI and a 6-speed Cruise Drive transmission, this motorcycle provides effortless cruising and unparalleled comfort. Its comfortable riding position, wind protection, and generous passenger room make it an ideal companion for long-distance journeys.
Whether you’re carving through twisties or cruising down the highway, the Heritage Softail Classic’s rigid-mount engine and Electronic Sequential Port Fuel Injection ensure a seamless, exhilarating ride every time.
Key Specifications
Engine Type
Four stroke, 45 V-Twin,Twin Cam 88 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Engine Capacity
88.4 cubic inches / 1449 cc
Max Power
67 hp / 48.8 kW @ 5200 rpm
Max Torque
86 ft-lb / 116.6 nm
Fuel Tank Capacity
5.0 US gallons / 19.0 L
Weight (Wet/Kerb)
738.5 lbs / 335 kg
Seat Height
25.4 inches / 645.2 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson FLSTC/I Heritage Softail Classic
Year
2005 – 2006
Engine
Engine Type
Four stroke, 45 V-Twin,Twin Cam 88 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Displacement
88.4 cubic inches / 1449 cc
Bore x Stroke
95.3 x 101.6 mm
Compression Ratio
8.9:1
Max Horsepower
67 hp / 48.8 kW @ 5200 rpm
Max Torque
86 ft-lb / 116.6 nm
Engine Management System
Carburetion 40 mm constant velocity with enrichener and accelerator pumpESPFI 38 mm throttle bore electronic sequential port fuel injection
Lubrication System
Dry sump, internally mounted, crank driven gerotor pressure and dual scavenge pump with spin on 10 pressurized oil filter
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Gear Ratios
1st 10.1102nd 6.9583rd 4.9534th 3.8625th 3.150
Final Drive
Belt
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
41.3 mm Telescopic forks, with beer can covers
Rear Suspension
Dual down-tubes Swing Arm Triangular hard tail style
Rake
32
Trail
147.3 mm / 5.8 in
Wheels & Brakes
Front Tire Size
1D402F MT90B16 72H
Rear Tire Size
D401 150/80B16 71H
Front Brakes
Single 292mm discs 4 piston calipers
Rear Brakes
Single 292mm disc 4 piston caliper
Dimension & Weights
Seat Height
25.4 inches / 645.2 mm
Wheelbase
64.5 inches / 1638.3 mm
Ground Clearance
130 mm / 5.1 in
Fuel Tank Capacity
5.0 US gallons / 19.0 L
Wet (kerb/curb) Weight
738.5 lbs / 335 kg
Dry Weight
317 kg / 699.0 lbs
Features
40 mm constant velocity carburetor with enrichener and accelerator pump
Electronic Sequential Port Fuel Injection (ESPFI) system
