Harley Davidson FLHXS Street Glide Special (2015)

Harley Davidson FLHXS Street Glide Special (2015)

The Harley-Davidson FLHXS Street Glide Special, the epitome of American touring motorcycles, has arrived with its unruly attitude and stripped-down bagger style intact.

Enhanced by Project RUSHMORE, this new generation of freedom machines boasts a Gloss Black inner fairing, Reflex Linked Brakes with ABS, and the innovative Boom! Box 6.5 GT infotainment system as standard equipment. The High Output Twin Cam 103 engine provides an unbridled rush of power, while the Batwing fairing’s Splitstream vent reduces rider head buffeting.

With its Harley-Davidson Touring chassis, this bike is designed for long-haul touring riders who demand more from their machine. Project RUSHMORE has recalibrated the expectations of the touring motorcyclist with technology and design enhancements that transform every ride into an unforgettable experience.

The Harley-Davidson FLHXS Street Glide Special is not just a motorcycle – it’s a statement of American freedom, unbridled power, and unrelenting style.

Key Specifications

Engine TypeFour stroke, V-Twin, Twin Cam 103 with Integrated Oil-Cooler
Engine Capacity1690 mm / 103 cu. in
Max Torque142 Nm / 14.5 kgf-m / 104.7 ft/lb @ 3250 rpm
Fuel Tank Capacity22.7 Litres / US 6.0 gal
Weight (Wet/Kerb)822 lbs / 373 kg
Seat Height26.1 inches / 663 mm
Harley Davidson FLHXS Street Glide Special (2015)

All Specifications

Make & Model

ModelHarley Davidson FLHXS Street Glide Special
Year2015

Engine

Engine TypeFour stroke, V-Twin, Twin Cam 103 with Integrated Oil-Cooler
Displacement1690 mm / 103 cu. in
Bore x Stroke98.4 x 111.3 mm
Compression Ratio9.7:1
Max Torque142 Nm / 14.5 kgf-m / 104.7 ft/lb @ 3250 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Cooling SystemAir cooled

Performance

Top Speedn/a

Transmission

Gearbox6 Speed
Gear Ratios1st 9.312 / 2nd 6.421 / 3rd 4.774 / 4th 3.926 / 5th 3.279/ 6th 2.790:1
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, square-section backbone with twin downtubes
Front Suspension41.3 mm telescopic, cartridge-style damping,
Front Suspension Travel4.6 inches / 117 mm
Rear SuspensionShort, air-adjustable shock
Rear Suspension Travel2.0 inches / 51 mm
Rake26
Trail170 mm / 6.7 in.

Wheels & Brakes

Front Wheel/Rim SizeBlack, Slotted 5-Spoke Cast Aluminum
Front Tire SizeD408F BW 130/70B18 63H
Rear Wheel/Rim SizeBlack, Slotted 5-Spoke Cast Aluminum
Rear Tire SizeD407 BW 180/65B16 81H
Front Brakes2 x 292 mm disc, 4 piston caliper
Rear BrakesSingle 292 mm disc, 4 piston caliper

Dimension & Weights

Seat Height26.1 inches / 663 mm
Wheelbase63.5 inches / 1613 mm
Ground Clearance135 mm / 5.3 in
Fuel Tank Capacity22.7 Litres / US 6.0 gal
Wet (kerb/curb) Weight822 lbs / 373 kg
Dry Weight354 kg / 775 lbs

Features

  • Gloss Black inner fairing
  • Reflex Linked Brakes with ABS
  • Boom! Box 6.5 GT infotainment system
  • CVO-style hand-adjustable lowered rear suspension
  • High Output Twin Cam 103 engine
  • Batwing fairing with Splitstream vent
  • Harley-Davidson Touring chassis
  • Single-spar, rigid backbone frame
  • Stout swingarm
  • Aerodynamic bodywork shaped by wind tunnel testing
  • Electronic Sequential Port Fuel Injection (ESPFI)
  • Improved power and braking performance
  • Enhanced rider ergonomics
  • Infotainment system with electronic controls
  • Comfortable seating for long-distance riding
