Harley Davidson FLHX Street Glide (2015)

Harley Davidson FLHX Street Glide (2015)

The Harley-Davidson FLHX Street Glide is a masterclass in American muscle, blending street-smart style with the raw power of its 103ci V-twin engine. This potent combination results in an astonishing 102ft-lbs of peak torque at just 3500rpm, making it more than capable of tackling both urban and open-road riding.

The innovative Electronic Sequential Port Fuel Injection (ESPFI) system, paired with heated oxygen sensors and Electronic Throttle Control, ensures seamless power delivery. This is further enhanced by the six-speed Cruise Drive transmission, precision-crafted suspension components, and a robust single-spar frame that deftly balances responsiveness with long-haul durability.

Riding the Street Glide is an immersive experience, as its low suspension and aggressive stance put you firmly in command. And when you need to take things up a notch, the bike’s Electronic Throttle Control system allows for effortless acceleration, while the precision-crafted suspension absorbs even the most uneven road surfaces with ease.

Key Specifications

Engine TypeFour stroke, V-Twin, Twin Cam 103 with Integrated Oil-Cooler
Engine Capacity1690 mm / 103 cu. in
Max Torque142 Nm / 14.5 kgf-m / 104.7 ft/lb @ 3250 rpm
Fuel Tank Capacity22.7 Litres / US 6.0 gal
Weight (Wet/Kerb)810 lbs / 372 kg
Seat Height26.1 inches / 663 mm
Harley Davidson FLHX Street Glide (2015)

All Specifications

Make & Model

ModelHarley Davidson FLHX Street Glide
Year2015

Engine

Engine TypeFour stroke, V-Twin, Twin Cam 103 with Integrated Oil-Cooler
Displacement1690 mm / 103 cu. in
Bore x Stroke98.4 x 111.3 mm
Compression Ratio9.7:1
Max Torque142 Nm / 14.5 kgf-m / 104.7 ft/lb @ 3250 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Cooling SystemAir cooled
ExhaustChrome, 2-1-2 dual exhaust with tapered mufflers

Performance

Top Speedn/a

Transmission

Gearbox6 Speed
Gear Ratios1st 9.312 / 2nd 6.421 / 3rd 4.774 / 4th 3.926 / 5th 3.279 / 6th 2.790:1
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, square-section backbone with twin downtubes
Front Suspension41.3 mm telescopic, cartridge-style damping,
Front Suspension Travel4.6 inches / 117 mm
Rear SuspensionShort, air-adjustable shock,
Rear Suspension Travel2.0 inches / 51 mm
Rake26
Trail170 mm / 6.7 in.

Wheels & Brakes

WheelsOptional Style Type Tubeless Chrome Aluminum Profile Laced
Front Wheel/Rim SizeBlack, Slotted 5-Spoke Cast Aluminum
Front Tire SizeD408F BW 130/70B18 63H
Rear Wheel/Rim SizeBlack, Slotted 5-Spoke Cast Aluminum
Rear Tire SizeD407 BW 180/65B16 81H
Front Brakes2 x 292 mm disc, 4 piston caliper
Rear BrakesSingle 292 mm disc, 4 piston caliper

Dimension & Weights

Seat Height26.1 inches / 663 mm
Wheelbase63.5 inches / 1613 mm
Fuel Tank Capacity22.7 Litres / US 6.0 gal
Wet (kerb/curb) Weight810 lbs / 372 kg
Dry Weight355 kg / 775 lbs

Features

  • Electronic Sequential Port Fuel Injection (ESPFI)
  • Twin Cam 103TM engine
  • Automatic Compression Release
  • Integrated oil cooler
  • 6-Speed Cruise DriveTM transmission
  • 41.3 mm telescopic front forks
  • Air-adjustable rear shocks
  • Isolated Drive System for smooth power delivery
  • Single-spar, rigid-backbone frame
  • Two-piece swingarm
  • Rubber-mounted engine
  • Electronic Throttle Control (ETC)
  • Heated O2 sensors
  • Security Package Option with Harley-Davidson Smart Security System and Anti-lock Braking System (ABS)
  • Custom floorboard for comfort and confidence
  • 18-inch front wheel with lower-profile, 130/80B18 tire
  • 2-into-1 exhaust and single, four-inch-diameter chrome muffler
  • Injection-molded hard saddlebags with colormatched latches; 26 cu. ft. volume
