The Harley-Davidson FLHX Street Glide is a beast of a bike, bred for the open road. Its Twin Cam 103 V-Twin engine roars to life with 102 ft-lbs of torque at 3500 rpm, propelling you effortlessly around town and on the highway.

Its street-wise soul is evident in its stripped-down trim and chrome accents, while the low suspension and blackened wind deflector add a touch of attitude. The innovative Touring chassis, based on a single-spar frame and stout swingarm, ensures responsive handling and long-haul durability.

With Electronic Sequential Port Fuel Injection (ESPFI) and heated O2 sensors, the engine is finely tuned for optimal performance. Add to that Electronic Throttle Control (ETC), and you have a bike that’s as comfortable on the highway as it is in the city. The result is an unforgettable riding experience that will leave you craving more.

The Harley-Davidson FLHX Street Glide is ready to roll, with its legendary V-Twin engine and touring chassis delivering unparalleled performance and style.

Key Specifications

Engine TypeFour stroke, V-Twin, ‘Twin Cam 96’
Engine Capacity96.6 cubic inches / 1584 cc
Max Torque124.7 Nm / 92 ft. lbs @ 3000 rpm
Fuel Tank Capacity22.7 Litres / 6.0 gal
Weight (Wet/Kerb)810 lbs / 367 kg
Seat Height26.3 inches / 668.0 mm
Harley Davidson FLHX Street Glide (2011)

All Specifications

Make & Model

ModelHarley Davidson FLHX Street Glide
Year2011

Engine

Engine TypeFour stroke, V-Twin, ‘Twin Cam 96’
Displacement96.6 cubic inches / 1584 cc
Bore x Stroke95.25 x 111.25 mm
Compression Ratio9.2:1
Max Torque124.7 Nm / 92 ft. lbs @ 3000 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Cooling SystemAir cooled

Performance

Top Speedn/a

Transmission

Gearbox6 Speed
Gear Ratios1st 9.312 9.312 9.312 2nd 6.421 6.421 6.421 3rd 4.774 4.774 4.774 4th 3.926 3.926 3.9265th 3.279 3.279 3.279 6th 2.790 2.790 2.790
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, square-section backbone with twin downtubes
Front Suspension41.3 mm telescopic, cartridge-style damping
Rear SuspensionShort, air-adjustable shock
Rake26
Trail170 mm / 6.7 in

Wheels & Brakes

Front Tire SizeMT90B16
Rear Tire SizeMU85B16
Front Brakes2x 292mm disc 4 piston caliper
Rear BrakesSingle 292mm disc 4 piston caliper

Dimension & Weights

Seat Height26.3 inches / 668.0 mm
Wheelbase63.5 inches / 1613 mm
Fuel Tank Capacity22.7 Litres / 6.0 gal
Wet (kerb/curb) Weight810 lbs / 367 kg

Features

  • Electronic Sequential Port Fuel Injection (ESPFI)
  • Twin Cam 103 V-Twin engine
  • Heated O2 sensors
  • Electronic Throttle Control (ETC)
  • Single-spar, rigid backbone frame
  • Stout swingarm
  • Isolated Drive System for smooth power delivery
  • 6-Speed Cruise Drive transmission
  • 41.3 mm telescopic front forks
  • Air-adjustable rear shocks
  • Tubeless Chrome Aluminum Profile Laced wheel option
  • New paint color options
  • Security Package Option with Harley-Davidson Smart Security System and ABS
  • Red stop/turn/tail lights with chrome bracket
  • Black powder-coated powertrain with chrome covers
  • Lowered rear suspension
  • Bat-wing, fork-mounted fairing with mini wind deflector
  • Chrome, low-profile fuel tank console
  • Deep FL front fender with no trim
