The Harley-Davidson FLHX Street Glide is a tour-de-force of style and substance, combining the best of both worlds for riders seeking comfort and customization.
Under the sleek “bat wing” fairing, the 1584cc Twin Cam 96 engine roars to life with its distinctive growl, effortlessly delivering power through the 6-speed Cruise Drive transmission.
As you ride, the Street Glide’s exceptional comfort features take center stage: the durable GTX nylon saddlebags, air-adjustable rear suspension, and triple-disc brakes all contribute to a smooth, confident experience on the open road. With its low seat height of just 26.3 inches and sleek Streamliner footboards, navigating twisties or cruising highways has never been more enjoyable.
Key Specifications
Engine Type
Four stroke, 45 V-Twin,Twin Cam 88 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Engine Capacity
88.4 cubic inches / 1449 cc
Max Torque
86 ft-lb / 116.6 nm
Fuel Tank Capacity
19 Litres / 5.0 gal
Weight (Wet/Kerb)
776 lbs / 352 kg
Seat Height
26.3 inches / 668.0 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson FLHX Street Glide
Year
2006
Engine
Engine Type
Four stroke, 45 V-Twin,Twin Cam 88 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Displacement
88.4 cubic inches / 1449 cc
Bore x Stroke
95.3 x 101.6 mm
Compression Ratio
8.9:1
Max Torque
86 ft-lb / 116.6 nm
Engine Management System
Carburetion 40 mm constant velocity with enrichener and accelerator pump or ESPFI 38 mm throttle bore electronic sequential port fuel injection
Lubrication System
Dry sump, internally mounted, crank driven gerotor pressure and dual scavenge pump with spin on 10 pressurized oil filter
*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
