The Harley-Davidson FLHTK Electra Glide Ultra Limited is the pinnacle of touring motorcycles. At its heart lies a Twin Cam 103TM engine, producing 102 ft-lbs of peak torque at 3500 rpm, delivering exceptional performance in town and on the open road.
This powerhouse is matched by a 6-Speed Cruise DriveTM transmission, air-adjustable rear shocks, and Isolated Drive System for smooth power delivery. The single-spar, rigid-backbone frame and two-piece swingarm ensure responsive maneuverability and long-haul durability.
Ride the FLHTK Electra Glide Ultra Limited and experience the epitome of touring comfort and performance, with every detail carefully crafted to provide an unparalleled riding experience.
Key Specifications
Engine Type
Four stroke, Twin Cam 103 with integrated oil cooler Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Engine Capacity
1690 cc / 103.1 cub in.
Max Torque
143 Nm / 105.4 ft/lb @ 3750 rpm
Fuel Tank Capacity
6.0 US gallons / 22.7 L
Weight (Wet/Kerb)
896 lbs / 414 kg
Seat Height
27.3 inches / 695 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson FLHTK Electra Glide Ultra Limited
Year
2012
Engine
Engine Type
Four stroke, Twin Cam 103 with integrated oil cooler Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Twin Cam 103TM engine with Automatic Compression Release
102 ft. lbs. of peak torque at 3500 rpm
6-Speed Cruise DriveTM transmission
Isolated Drive System for smooth power delivery
Single-spar, rigid-backbone frame
Two-piece swingarm designed for responsive manoeuvrability and long-haul durability
Air-adjustable rear shocks
41.3 mm telescopic front forks
Electronic Sequential Port Fuel Injection (ESPFI)
Heated O2 sensors
Electronic Throttle Control (ETC)
Integrated oil cooler
Bat-wing, fork-mounted fairing with clear, Lexan windshield
Smoked Lexan adjustable fairing-mounted air deflectors
Vented removable lower fairings with integral storage compartments
Injection-molded hard saddlebags with liners; 2.26 cu. ft. volume
Injection Molded hard Tour-Pak with soft luggage liners, storage pockets, wrap-around rear tail/brake lights and 12-volt, 15 amp power supply; 2.26 cu. ft. volume
Premium Tour-Pak luggage rack
