Harley Davidson FLHTCUTG Tri Glide Ultra Classic (2013)

The Harley-Davidson FLHTCUTG Tri Glide Ultra Classic is a masterfully crafted three-wheeled touring machine that embodies the essence of freedom on the open road.

At its heart lies a powerful Twin Cam 103 engine, delivering authentic performance and excitement in a package that’s unmistakably Harley-Davidson. The ride experience is further enhanced by a lengthened and raked front fork with steering damper, providing exceptional stability and control.

Loaded with luxurious features like a deluxe Tour-Pak carrier and integrated trunk for ample storage, electronic cruise control, electric reverse drive, and a premium 4-speaker, 80-watt Harmon/Kardon Advanced Audio System, the Tri Glide Ultra Classic is designed to redefine long-haul comfort and convenience. Whether cruising down the highway or navigating twisty roads, this trike inspires confidence, passion, and independence in every riding situation, making it ready to confidently chase the horizon with you at the helm.

Key Specifications

Engine Type	Four stroke, Twin Cam 103 Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters: two valves per cylinder
Engine Capacity	1690 cc / 103.1 cub in.
Max Torque	138 Nm / 14.1 kgf-m / 101.8 ft/lb / @ 3750 rpm
Fuel Tank Capacity	6.0 US gallons / 22.7 L
Weight (Wet/Kerb)	1235 lbs / 560 kg
Seat Height	28.3 inches / 720 mm

*n/a – information not provided by manufacturer

Harley Davidson FLHTCUTG Tri Glide Ultra Classic (2013)

All Specifications

Make & Model

Model	Harley Davidson FLHTCUTG Tri Glide Ultra Classic
Year	2013

Engine

Engine Type	Four stroke, Twin Cam 103 Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters: two valves per cylinder
Displacement	1690 cc / 103.1 cub in.
Bore x Stroke	98.4 x 111.1 mm
Compression Ratio	10.0:1
Max Torque	138 Nm / 14.1 kgf-m / 101.8 ft/lb / @ 3750 rpm
Engine Management System	Electronic Sequential Port Fuel Injection (ESPFI)
Cooling System	Air/water cooled
Exhaust	Chrome, 2-1-2 dual exhaust with tapered mufflers

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Multi-plate, wet
Gearbox	6 Speed
Gear Ratios	1st 10.537 / 2nd 7.303 / 3rd 5.423 / 4th 4.392 / 5th 3.741 / 6th 3.157:1
Final Drive	Belt

Electrical & Electronics System

Starter

Electric

Chassis & Suspension

Frame Type	Mild steel, square-section backbone with twin downtubes Swingarm Mild steel, rectangular tube sections with plate junctions; MIG welded
Front Suspension	41.3 mm telescopic, triple-circuit damping,
Front Suspension Travel	4.6 inches / 117 mm
Rear Suspension	Air-adjustable
Rear Suspension Travel	2.9 inches / 76 mm
Rake	26
Trail	100 mm / 3.94 in

Wheels & Brakes

Front Wheel/Rim Size	Black, 7-spoke cast aluminium
Front Tire Size	MT90B16 72H
Rear Tire Size	2x P205/65R15
Front Brakes	2 x 300mm disc, 4 piston caliper
Rear Brakes	2 x 229mm disc, 1 piston caliper

Dimension & Weights

Seat Height	28.3 inches / 720 mm
Wheelbase	65.8 inches / 1670 mm
Ground Clearance	135 mm / 5.3 in
Fuel Tank Capacity	6.0 US gallons / 22.7 L
Wet (kerb/curb) Weight	1235 lbs / 560 kg
Dry Weight	545 kg / 1202 lbs

Features

Ultra-comfortable long haul conveniences
Large Twin Cam 103 engine
Lengthened and raked front fork with steering damper
Deluxe Tour-Pak carrier and integrated trunk for storage
6.5 cubic feet of storage capacity
4-speaker, 80-watt Harmon/Kardon Advanced Audio System
Electronic cruise control
Electric reverse drive
Black powder-coated engine with chrome covers
Chrome 2-1-2 dual exhaust with tapered mufflers
Split, 7-Spoke Black-and-Machined Cast Aluminum wheels
Bat-wing, fork-mounted fairing with clear, Lexan windshield
Smoked Lexan adjustable fairing-mounted air deflectors
Vented removable lower fairings with integral storage compartment
Chrome, low-profile fuel tank console
Fairing-mounted electronic speedometer and tachometer gauges
Injection Molded hard Tour-Pak with soft luggage liners and rear tail/brake lights
Passenger backrest and arm rests
