Harley Davidson FLHTCU SE5 Electric Glide Ultra Classic CVO (2010)

The Harley-Davidson FLHTCU SE5 Electric Glide Ultra Classic CVO embodies the essence of high-performance touring. Built on the innovative Touring chassis introduced in 2009, this powerhouse features an Electronic Sequential Port Fuel Injection (ESPFI) system, delivering unmatched power and efficiency.

A plethora of premium accessories elevates the riding experience, including a luxurious leather passenger backrest with adjustable lumbar support, perforated printed inserts for the seat and rider backrest, and brilliant white LED light pods illuminating the saddlebag interiors. The 110ci Screamin’ Eagle engine produces a robust soundtrack, thanks to rumble collection components and custom exhaust.

With its stunning custom paint scheme, exclusive to this limited-production model, the FLHTCU SE5 is sure to turn heads on any open road. This exceptional touring machine offers an unparalleled blend of style, performance, and luxury features, making it the ultimate choice for discerning riders who demand nothing but the best.

Key Specifications

Engine Type	Four stroke, Twin Cam 110 with integrated oil cooler Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Engine Capacity	1802 cc / 109.96 cub in.
Max Torque	156 Nm / 15.9 kgf-m / 115 ft. lbs @ 3750 rpm
Fuel Tank Capacity	6.0 US gallons / 22.7 L
Weight (Wet/Kerb)	933 lbs / 423.2 kg
Seat Height	27.8 inches / 706 mm

*n/a – information not provided by manufacturer

Harley Davidson FLHTCU SE5 Electric Glide Ultra Classic CVO (2010)

All Specifications

Make & Model

Model	Harley Davidson FLHTCU SE5 Electric Glide Ultra Classic CVO
Year	2010

Engine

Engine Type	Four stroke, Twin Cam 110 with integrated oil cooler Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Displacement	1802 cc / 109.96 cub in.
Bore x Stroke	101.6 x 111.1 mm
Compression Ratio	9.2:1
Max Torque	156 Nm / 15.9 kgf-m / 115 ft. lbs @ 3750 rpm
Engine Management System	Electronic Sequential Port Fuel Injection (ESPFI)
Cooling System	Air/Liquid cooled,

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Multi-plate, wet
Gear Ratios	1st 9.312 9.312 9.030 / 2nd 6.421 6.421 6.226 / 3rd 4.774 4.774 / 4.630 / 4th 3.926 3.926 3.807 / 5th 3.279 3.279 3.179 / 6th 2.790 2.790 2.706
Final Drive	Belt

Electrical & Electronics System

Starter

Electric

Chassis & Suspension

Frame Type	Mild steel, sqaure-section backbone with twin downtubes
Front Suspension	41.3 mm telescopic forks,
Front Suspension Travel	116 mm /
Rear Suspension	Swing Arm Mild steel, rectangular tube sections, stamped junctions; MIG welded, Lowered, air-adjustable,
Trail	170 mm / 6.6 in

Wheels & Brakes

Front Tire Size	D408 130/80B17 65H
Rear Tire Size	D407 180/65B16 81H
Front Brakes	2x 300mm discs 4 piston calipers, ABS Standard
Rear Brakes	Single 300mm disc 4 piston caliper, ABS Standard

Dimension & Weights

Seat Height	27.8 inches / 706 mm
Wheelbase	63.5 inches / 1613 mm
Fuel Tank Capacity	6.0 US gallons / 22.7 L
Wet (kerb/curb) Weight	933 lbs / 423.2 kg

Features

Electric Glide Ultra Classic CVO model designation
Electronic Sequential Port Fuel Injection (ESPFI)
Single-spar, rigid backbone frame
Stout swingarm
Custom paint scheme with color-matched inner fairing assembly and rear fender filler strips
Leather passenger backrest with adjustable lumbar support
Perforated printed inserts for seat and rider backrest
Brilliant white LED light pods illuminate saddlebag interiors
Dimpled inserts for CB pod, Tour-Pak lid, and Screamin Eagle 110 insert
Tour-Pak 12 Volt Outlet
Custom Vehicle Operations medallions on rear fender and fuel door
Custom Vehicle Operations carry-out luggage liners for Tour-Pak and saddlebags
Plush Tour-Pak bottom liner with CVO monogram
Suspended, dual-control heated leather seat
Screamin Eagle Twin Cam 110 Granite powder-coated powertrain
Rumble Collection rider and passenger footboard inserts
Roulette Wheels
Teardrop floating front brake rotors
Custom oil cooler with chrome cover and CVO medallion
80-watt Harman/Kardon Advanced Audio System with CB/intercom and navigation system
Anti-Lock Brakes
Electronic Cruise Control
Air Wing Tour-Pak rack
Saddlebag and Tour-Pak power lock system

*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
