Harley Davidson FLHTCU Electra Glide Ultra Classic (2013)

Harley Davidson FLHTCU Electra Glide Ultra Classic (2013)

The iconic Harley-Davidson FLHTCU Electra Glide Ultra Classic is the epitome of long-haul touring excellence. Its Electronic Sequential Port Fuel Injection (ESPFI) system ensures a seamless combustion experience, while the Twin Cam 103 engine delivers an astonishing 102 ft-lbs of peak torque at 3500 rpm.

As you settle into the plush one-piece, two-up Electra Glide Classic comfort stitch seat, complete with passenger backrest and Harmon/Kardon Advanced Audio System, you’ll be treated to a symphony of touring comforts. The adjustable fairing-mounted air deflectors, vented removable fairing lowers with integral glove boxes, and injection-molded hard saddlebags all contribute to an atmosphere of relaxed elegance.

With its responsive manoeuvrability, long-haul durability, and confident handling, the Harley-Davidson Touring chassis is the perfect platform for exploring the open road. And as you ride off into the sunset, one thing becomes clear: the Harley-Davidson FLHTCU Electra Glide Ultra Classic sets a new standard for touring excellence that’s simply unmatched.

Key Specifications

Engine TypeFour stroke, V-Twin, High output ‘Twin Cam 103’
Engine Capacity1690 cc / 103.1 cub in.
Max Torque138 Nm / 14.1 kgf-m / 101.8 ft. lbs @ 3750 rpm
Fuel Tank Capacity6.0 US gallons / 22.7 L
Weight (Wet/Kerb)906 lbs / 411 kg
Seat Height27.3 inches / 693 mm
Harley Davidson FLHTCU Electra Glide Ultra Classic (2013)

All Specifications

Make & Model

ModelHarley Davidson FLHTCU Electra Glide Ultra Classic
Year2013

Engine

Engine TypeFour stroke, V-Twin, High output ‘Twin Cam 103’
Displacement1690 cc / 103.1 cub in.
Bore x Stroke98.4 x 111.1 mm
Compression Ratio10.0:1
Max Torque138 Nm / 14.1 kgf-m / 101.8 ft. lbs @ 3750 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Cooling SystemAir cooled
ExhaustChrome, 2-1-2 dual exhaust with tapered mufflers

Performance

Top Speedn/a

Transmission

ClutchMulti-plate, wet
Gearbox6 Speed
Gear Ratios1st 9.5932nd 6.653rd 4.9384th 4.05th 3.4076th 2.875
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, square-section backbone with twin downtubes
Front Suspension41.3 mm telescopic, cartridge-style damping
Rear SuspensionShort, air-adjustable shock
Rake26
Trail170 mm / 6.7 in

Wheels & Brakes

Front Tire SizeBW 130/80B17 65H
Rear Tire SizeBW 180/65B16 81H
Front Brakes2 x 292 mm disc, 4 piston caliper
Rear BrakesSingle 292 mm disc, 4 piston caliper

Dimension & Weights

Seat Height27.3 inches / 693 mm
Wheelbase63.9 inches / 1625 mm
Ground Clearance130 mm / 5.1 in
Fuel Tank Capacity6.0 US gallons / 22.7 L
Wet (kerb/curb) Weight906 lbs / 411 kg
Dry Weight394 kg / 869 lbs

Features

  • 80-watt Harmon/Kardon Advanced Audio System
  • Fourspeaker audio system
  • One-piece, two-up Electra Glide Classic comfort stitch seat with passenger backrest
  • Adjustable fairing-mounted air deflectors
  • Vented removable fairing lowers with integral glove boxes
  • Spacious Tour-Pak carrier and injection-molded hard saddlebags
  • Standard electronic cruise control
  • Twin Cam 103TM engine
  • Automatic Compression Release
  • Integrated oil cooler
  • 102 ft. lbs. of peak torque at 3500 rpm
  • 6-Speed Cruise DriveTM transmission
  • 41.3 mm telescopic front forks
  • Air-adjustable rear shocks
  • Isolated Drive System for smooth power delivery
  • Single-spar, rigid-backbone frame
  • Two-piece swingarm for responsive manoeuvrability and long-haul durability
  • Tubeless Chrome Lace Aluminium Wheel option (new)
  • Rubber-mounted Twin Cam 103 V-Twin engine with ESPFI
