Harley Davidson FLHTC Electra Glide Classic (2013)

Harley Davidson FLHTC Electra Glide Classic (2013)

The Harley-Davidson FLHTC Electra Glide Classic is a touring behemoth that embodies the essence of American motorcycling. Powered by the potent 1690cc Twin Cam 103 V-Twin engine, this machine unleashes a torrent of torque and character that’s both raw and refined.

The rubber-mounted engine, paired with Electronic Sequential Port Fuel Injection (ESPFI) and Electronic Throttle Control (ETC), delivers seamless power delivery and effortless shifting through its six-speed Cruise Drive transmission. Whether navigating twisties or cruising down the highway, the Electra Glide Classic’s smooth-shifting gearbox and responsive throttle make every ride a pleasure.

With its robust Harley-Davidson Touring chassis, this bike is built for long-haul touring adventures. The innovative single-spar, rigid backbone frame and stout swingarm provide a rock-solid foundation for the bike’s impressive payload capacity. And with ample storage space in the Tour-Pak carrier and saddlebags, you can bring all your gear along for the ride.

Riding the Electra Glide Classic is an immersive experience that envelops you in luxury and comfort. The air-adjustable rear shocks soak up bumps, while the ergonomic touring handlebar and sculpted seat provide optimal support and control. Whether you’re a seasoned rider or just starting out, this bike’s intuitive ergonomics and refined ride quality make it accessible to all.

The Electra Glide Classic is the ultimate expression of Harley-Davidson’s touring expertise, combining exceptional performance, luxurious amenities, and timeless style that leaves an indelible mark on the open road. It’s a machine that demands attention, commands respect, and rewards its rider with a truly unforgettable experience – every time you fire up the engine.

Key Specifications

Engine TypeFour stroke, V-Twin, High output ‘Twin Cam 103’
Engine Capacity1690 cc / 103.1 cub in.
Max Torque138 Nm / 14.1 kgf-m / 101.8 ft. lbs @ 3750 rpm
Fuel Tank Capacity6.0 US gallons / 22.7 L
Weight (Wet/Kerb)911 lbs / 413 kg
Seat Height27.3 inches / 693.42 mm
Harley Davidson FLHTC Electra Glide Classic (2013)

All Specifications

Make & Model

ModelHarley Davidson FLHTC Electra Glide Classic
Year2013

Engine

Engine TypeFour stroke, V-Twin, High output ‘Twin Cam 103’
Displacement1690 cc / 103.1 cub in.
Bore x Stroke98.4 x 111.1 mm
Compression Ratio10.0:1
Max Torque138 Nm / 14.1 kgf-m / 101.8 ft. lbs @ 3750 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Cooling SystemAir cooled
ExhaustChrome, 2-1-2 dual exhaust with tapered mufflers

Performance

Top Speedn/a

Transmission

Gearbox6 Speed
Gear Ratios1st 9.593 2nd 6.650 3rd 4.938 4th 4.000 5th 3.407 6th 2.875
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, square-section backbone with twin downtubes
Front Suspension41.3 mm telescopic, cartridge-style damping
Rear SuspensionShort, air-adjustable shock

Wheels & Brakes

Front Tire SizeMT90B16
Rear Tire SizeMU85B16
Front Brakes2x 292mm disc 4 piston caliper
Rear BrakesSingle 292mm disc 4 piston caliper

Dimension & Weights

Seat Height27.3 inches / 693.42 mm
Fuel Tank Capacity6.0 US gallons / 22.7 L
Wet (kerb/curb) Weight911 lbs / 413 kg
Dry Weight400 kg / 882 lbs

Features

  • Electronic Sequential Port Fuel Injection (ESPFI) system
  • Twin Cam 103 V-Twin engine with heated O2 sensors and Electronic Throttle Control (ETC)
  • Black powder-coated powertrain with chrome covers
  • Chrome 2-1-2 dual exhaust with tapered mufflers
  • Black, 28-spoke Cast Aluminum wheels with whitewall tires
  • Tubeless Chrome Aluminum Profile Laced wheel option
  • Bat-wing, fork-mounted fairing with clear windshield
  • Chrome, low-profile fuel tank console
  • Deep FL front fender with trim
  • Stainless steel, easy-reach touring handlebar
  • One-piece, two-up Electra Glide classic comfort stitch seat
  • Passenger backrest with wrap-around armrests
  • Injection-molded hard saddlebags; 2.26 cu. ft. volume
  • Fairing-mounted electronic speedometer and tachometer
  • 40-watt, two-speaker Advanced Audio System by Harman/Kardon
