The Harley-Davidson FLHS 1340 Electra Glide is the epitome of touring motorcycles, designed to conquer long distances with ease and comfort.
Its massive 1340cc V-twin engine provides an abundance of torque at low revs, making it perfectly suited for navigating winding roads and varying terrain. The engine’s character is both smooth and responsive, delivering a unique riding experience that’s as enjoyable on the highway as it is in twisty backroads.
Whether you’re traversing the open plains or negotiating mountain passes, the Electra Glide’s low seat height and well-sprung suspension ensure an incredibly stable ride, allowing you to focus on taking in the breathtaking views rather than wrestling with the bike. With its powerful engine, comfortable ergonomics, and confident handling, this Harley-Davidson is the ultimate machine for anyone embarking on a long-distance adventure.
The Harley-Davidson FLHS 1340 Electra Glide is truly the perfect companion for those who crave freedom on two wheels.
Key Specifications
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Engine Capacity
81.7 cubic inches / 1337 cc
Max Power
67 hp /48.9hp @ 5000 rpm
Max Torque
69 lb-ft @ 3000 rpm
Fuel Tank Capacity
5.0 US gallons / 19.0 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Harley Davidson FLHS 1340 Electra Glide
Year
1978 – 79
Engine
Engine Type
Four stroke, 45 V-Twin, OHV, 2 valves per cylinder.
Displacement
81.7 cubic inches / 1337 cc
Bore x Stroke
88.8 x 108.0 mm
Compression Ratio
8.5:1
Max Horsepower
67 hp /48.9hp @ 5000 rpm
Max Torque
69 lb-ft @ 3000 rpm
Engine Management System
38mm KeihinCarburettor
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
Telescopic forks
Rear Suspension
Dual shocks swinging arm
Wheels & Brakes
Front Tire Size
MT90-16T
Rear Tire Size
MT90-16
Front Brakes
Single 254mm disc 1 piston caliper
Rear Brakes
Single 254mm disc 1 piston caliper.
Dimension & Weights
Fuel Tank Capacity
5.0 US gallons / 19.0 L
Dry Weight
343 kg / 756 lbs
Features
Here is the list of key features, standard equipment, and technical highlights:
Big, uncomplicated low-revving engine with lots of torque
Well-sprung rolling chassis
Comfortable seating arrangement
Vast dollops of luggage space
Good lighting system
Full coverage fairing
Purpose-built machine for heavy-duty touring
