Harley Davidson Electra Glide Standard (2019 – 2020)

Harley Davidson Electra Glide Standard (2019 - 2020)

The Harley-Davidson Electra Glide Standard is a stripped-down, high-octane touring machine that embodies the raw essence of its Grand American roots.

Powered by the muscular Milwaukee-Eight 107 engine, this rugged beauty delivers a fundamental riding experience, unencumbered by modern distractions. The engine’s characteristic V-Twin growl and snarl are unmistakable, as it effortlessly propels the bike through the gears: 9.593 in first, 4.0 in fourth, and a screaming 2.875 in sixth.

With its iconic batwing fairing, chrome trim, and standard saddle bags, the Electra Glide Standard is a masterclass in timeless design. Chrome accents are strategically placed to emphasize the engine’s V-Twin shape, while select blacked-out components add a touch of modernity. As Harley-Davidson’s Vice President of Styling & Design Brad Richards puts it: “We focused on finishes that were simple, timeless, and fundamental to the touring line.” The result is a bike that exudes a sense of nostalgia and tradition, yet remains utterly contemporary in its execution.

The Electra Glide Standard offers an unbridled riding experience, untainted by technology or frills. By stripping away unnecessary features, Harley-Davidson has created a true touring machine for the purist, one that rewards riders with a deep connection to the road and their surroundings.

Key Specifications

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Engine Capacity1746 cc / 107 cub in
Max Torque110.6 ft-lb / 150 nm
Fuel Tank Capacity6.0 US gallons / 22.7 L
Weight (Wet/Kerb)820 lbs / 372 kg
Seat Height26.8 inches / 680 mm
Harley Davidson Electra Glide Standard (2019 - 2020)

All Specifications

Make & Model

ModelHarley Davidson Electra Glide Standard
Year2019 – 2020

Engine

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Displacement1746 cc / 107 cub in
Bore x Stroke100 x 111 mm / 3.937 x 4.374 in
Compression Ratio10.0:1
Max Torque110.6 ft-lb / 150 nm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Lubrication SystemPressurized, dry-sump with oil cooler
Cooling SystemAir cooled
ExhaustChrome, 2-1-2 dual exhaust with tapered mufflers

Performance

Top Speedn/a

Transmission

ClutchMulti-plate, wet
Gearbox6 Speed
Gear Ratios1st 9.593 2nd 6.65 3rd 4.938 4th 4.0 5th 3.407 6th 2.875
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, square-section backbone with twin downtubes
Front Suspension41.3 mm telescopic, cartridge-style damping
Rear SuspensionShort, air-adjustable shock
Rake26
Trail170 mm / 6.7 in

Wheels & Brakes

Front Tire Size130/80B17 65H
Rear Tire Size180/65B16 81H
Front Brakes2 x 292mm disc, 4 piston caliper
Rear BrakesSingle 292mm disc, 4 piston caliper

Dimension & Weights

Seat Height26.8 inches / 680 mm
Wheelbase64 inches / 1625 mm
Ground Clearance120 mm / 4.7 in
Fuel Tank Capacity6.0 US gallons / 22.7 L
Wet (kerb/curb) Weight820 lbs / 372 kg
Dry Weight354 kg / 780 lbs

Features

  • Four stroke, V-Twin engine
  • Milwaukee-Eight 107 engine
  • Pushrod-operated overhead valves
  • Hydraulic, self-adjusting lifters
  • 4 valves per cylinder
  • Single-fire, non-wasted, map-controlled spark ignition
  • 6-speed transmission
  • Mild steel backbone with twin downtubes
  • Iconic batwing fairing
  • Chrome trim and accents
  • Standard saddle bags
  • Cast aluminum wheels
  • Polished rocker covers
  • Chrome derby covers
  • Electronic cruise control
  • Hand-adjustable emulsion-technology rear shock absorbers
  • 49mm front forks with Showa dual bending valve suspension
  • Brembo brakes
  • Optional Reflex Linked and ABS features
