The Harley-Davidson Dyna Low Rider is a masterclass in custom cruiser design, blending timeless style with exhilarating performance.

Underpinned by the agile Dyna chassis, this motorcycle is crafted for all-day comfort and precision handling. The Twin Cam 103 engine delivers its signature growl through sculpted header pipes feeding a throaty 2-into-1 exhaust. Meanwhile, advanced ergonomics provide a tailored fit to most riders, courtesy of adjustable handlebars and a two-position seat with removable bolster.

The result is an unparalleled riding experience that embodies the essence of Harley-Davidson’s heritage. From its ’70s-inspired seat to its chunky mag wheels, every detail has been meticulously crafted to evoke a sense of nostalgia and sophistication. The Low Rider is more than just a motorcycle – it’s an indulgence for the senses.

The Dyna Low Rider is a testament to the art of motorcycle design, where form meets function in perfect harmony.

Key Specifications

Engine TypeFour stroke, V-Twin, Twin Cam 103 with integrated oil cooler
Engine Capacity1690 cc / 103.1 cu in
Max Torque126 Nm / 112.8 kgf-m / 92.9 ft-lb @ 3500 rpm
Fuel Tank Capacity17.8 L / 4.7 US gal
Weight (Wet/Kerb)686 lbs / 311 kg
Seat Height27.25 inches / 692 mm
Harley Davidson Dyna Low Rider (2014 - 2015)

All Specifications

Make & Model

ModelHarley Davidson Dyna Low Rider
Year2014 – 2015

Engine

Engine TypeFour stroke, V-Twin, Twin Cam 103 with integrated oil cooler
Displacement1690 cc / 103.1 cu in
Bore x Stroke98.4 x 111.1 mm
Compression Ratio9.6:1
Max Torque126 Nm / 112.8 kgf-m / 92.9 ft-lb @ 3500 rpm
Engine Management SystemElectronic Sequential Port Fuel Injection (ESPFI)
Cooling SystemAir cooled
Exhaust2-into-1 Exhaust with a deep rumble

Performance

Top Speedn/a

Transmission

Gearbox6 Speed
Gear Ratios1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.790:1
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded
Front Suspension49 mm with polished aluminum fork triple clamp and dual-rate springs
Rear SuspensionCoil over shock
Rake30.5
Trail128 mm / 5.1 in

Wheels & Brakes

Front Wheel/Rim SizeChrome, steel laced ( optional: Black, split 5-spoke cast aluminium)
Front Tire Size100/90B19 57H
Rear Wheel/Rim SizeChrome, steel laced ( optional: Black, split 5-spoke cast aluminium)
Rear Tire Size160/70B17 73V
Front BrakesSingle 300 mm disc, 4 piston fixed caliper
Rear BrakesSingle 292 mm disc, 2 piston torque free floatingcaliper

Dimension & Weights

Seat Height27.25 inches / 692 mm
Wheelbase64.2 inches / 1630 mm
Ground Clearance105 mm / 4.13 in
Fuel Tank Capacity17.8 L / 4.7 US gal
Wet (kerb/curb) Weight686 lbs / 311 kg
Dry Weight296 kg / 653 lbs

Features

  • Electronic Sequential Port Fuel Injection (ESPFI)
  • Twin Cam 103 engine with Wrinkle Black and chrome-plated covers
  • 6-speed Cruise Drive transmission
  • Handlebar riser offers 2.4 inches of adjustment
  • Two-position ergonomic seat with a removable bolster
  • High-performance perforated seat cover features classic stitching pattern
  • Mid-mounted foot controls positioned to best fit most riders
  • Split 5-Spoke Cast Aluminum wheels finished in Wrinkle Black with diamond cut highlights
  • Chrome 2-into-1 exhaust
  • Console finished in Wrinkle Black holds an analog speedometer and tachometer
  • Chrome-plated rear fender strut covers feature Wrinkle Black cutouts
  • Classic headlamp visor
  • Polished front end
  • Dual disc front brakes
  • Michelin Scorcher 31 front and rear tires
  • Custom ignition switch located on the left side of the motorcycle
