Harley Davidson CVO Street Glide (2019)

Harley Davidson CVO Street Glide (2019)

The Harley-Davidson CVO Street Glide is the epitome of custom touring excellence, boasting the Milwaukee-Eight 117 V-Twin engine’s raw power and distinctive red rocker covers.

This imposing motorcycle is further elevated by premium custom paint, sleek Talon wheels, and bespoke controls that exude an air of exclusivity. The BOOM! Box GTS infotainment system takes center stage, delivering 900 watts of crystal-clear audio performance through three separate amplifiers.

A wireless headset interface allows seamless communication between rider, passenger, and other riders, while heated grips add a touch of comfort to the riding experience.

The CVO Street Glide’s aggressive styling is matched only by its impressive capabilities, making it the ultimate machine for those who crave both style and substance.

Key Specifications

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 117, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Engine Capacity117 cubic inches / 1923 cc
Max Torque124.6 ft-lb / 169 nm
Fuel Tank Capacity6.0 US gallons / 22.7 L
Weight (Wet/Kerb)877 lbs / 398 kg
Seat Height27.1 inches / 695 mm
Harley Davidson CVO Street Glide (2019)

All Specifications

Make & Model

ModelHarley Davidson CVO Street Glide
Year2019

Engine

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 117, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Displacement117 cubic inches / 1923 cc
Bore x Stroke103.5 X 114.3 mm
Compression Ratio10.2:1
Max Torque124.6 ft-lb / 169 nm
Engine Management SystemElectronic Sequential Port Fuel Injection
Lubrication SystemPressurized, dry-sump with oil cooler
Cooling SystemAir cooled
ExhaustDual, with crossover

Performance

Top Speedn/a

Transmission

Gearbox6 Speed
Gear Ratios1st 9.593 2nd 6.65 3rd 4.938 4th 4 5th 3.407 6th 2.875
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMild steel, square-section backbone with twin downtubes
Front SuspensionShowa dual bending valve front suspension
Rear SuspensionEmulsion rear suspension with hand-adjustable pre-load
Rake26
Trail170 mm / 6.7 in

Wheels & Brakes

Front Wheel/Rim SizeGloss Black and Contrast Chrome Talon
Front Tire Size130/60B19 61H
Rear Wheel/Rim SizeGloss Black and Contrast Chrome Talon
Rear Tire Size180/65B16 80H
Front BrakesCaliper Type 32 mm, 4-piston fixed
Rear BrakesCaliper Type 32 mm, 4-piston fixed

Dimension & Weights

Seat Height27.1 inches / 695 mm
Wheelbase64.0 inches / 1625 mm
Ground Clearance130 mm / 5.1 in
Fuel Tank Capacity6.0 US gallons / 22.7 L
Wet (kerb/curb) Weight877 lbs / 398 kg
Dry Weight382 kg / 842 lbs

Features

  • Emulsion rear suspension with hand-adjustable pre-load
  • Milwaukee-Eight 117 V-Twin engine
  • Red rocker covers
  • Premium custom paint
  • Premium Talon wheels
  • Custom controls
  • All-new BOOM! Box GTS infotainment system
  • 3 separate amplifiers, 75 watts per channel
  • 900 watts of clear audio performance
  • Wireless headset interface for Bluetooth connectivity
  • Heated grips
  • CVO Fade Paint finish treatment
  • Black Onyx physical vapor deposition exhaust finish
  • Exclusive paint colors and designs
  • Contrast Chrome Talon wheels option
  • Anodize Talon wheels option
  • Kahuna Collection with red Bar & Shield inset on some components
