Harley Davidson CVO Road Glide ST (2026)

2026-harley-davidson-cvo-road-glide-st-4-throttlecraze.com

The 2026 CVO Road Glide ST is Harley-Davidson’s race-inspired bagger at its most ruthless. Its Milwaukee-Eight® 121 High Output motor delivers unbelievable power and performance, fed by a Heavy Breather intake and finished with titanium-capped mufflers. Forged carbon fiber details, tall risers with a factory moto-bar setup, remote-reservoir suspension, and specialized track modes give it the look and feel of a purpose-built weapon engineered to outpace everything around you. The only thing faster than the way it looks is the way it moves.

Key Specifications

Engine TypeMilwaukee-Eight® 121 High Output
Engine Capacity121 cubic inches / 1983 cc
Max Power127 HP / 95 kW @ 4900 rpm
Max Torque145 ft-lb / 196.6 Nm @ 4000 rpm
Fuel Tank Capacity6 US gallons / 22.7 L
Weight (Wet/Kerb)838 lbs / 380.1 kg
Seat Height26.7 inches / 678.2 mm (laden)
2026-harley-davidson-cvo-road-glide-st-5-throttlecraze.com

All Specifications

Make & Model

ModelHarley Davidson CVO Road Glide ST
Year2026

Engine

Engine TypeMilwaukee-Eight® 121 High Output
Displacement121 cubic inches / 1983 cc
Bore x Stroke4.1 inches x 4.6 inches
103.5 mm x 116.8 mm
Compression Ratio11.4:1
Max Horsepower127 HP / 95 kW @ 4900 rpm
Max Torque145 ft-lb / 196.6 Nm @ 4000 rpm
Fuel-mixture SystemElectronic Sequential Port Fuel Injection (ESPFI)
Exhaust System2-1-2 dual exhaust with tapered mufflers

Performance

Acceleration (0-100 km/h, 0-60 mph)n/a
Fuel Consumption44 mpg / 18.7 kmpl
Range~ 264 miles / 424.9 kms

Transmission

Gearbox6-Speed
Primary Drive Ratio34:46
Gear Ratios1st gear – 10.233
2nd gear – 7.093
3rd gear – 5.268
4th gear – 4.266
5th gear – 3.635
6th gear – 3.067
Traction Control SystemC-TCS

Electrical & Electronics System

Headlight TypeLED
Taillight TypeLED
InstrumentationSkyline™ OS 12.3 inch Full Color TFT screen
ConnectivityApple CarPlay (wireless or wired); Bluetooth: Phone/Media Player, Headset
Riding ModesRoad, Rain, Sport, Track, Track+, and three Custom options
Traction Control SystemC-TCS
ABSC-ABS

Chassis & Suspension

Front Suspension1.9 in. Inverted 1×1 Front Forks with adjustable preload, compression damping and rebound damping
Rear SuspensionEmulsion suspension with adjustable preload, compression damping and rebound damping
Rake26
Trail6.7 inches / 170.2 mm

Wheels & Brakes

WheelsBlack, 7-spoke Cast Aluminum
Front Wheel/Rim Size19 in.
Front Tire Size130/60B19 M/C 61H
Rear Wheel/Rim Size18 in.
Rear Tire Size180/55B18 M/C 80H
Front BrakesWave Style, dual floating rotors (front), fixed rotor (rear), 4-piston fixed dual radial mounted front
Rear BrakesSingle axial mounted rear
ABSC-ABS

Dimension & Weights

Overall Length94.9 inches / 2410.5 mm
Overall Width36.4 inches / 924.6 mm
Seat Height26.7 inches / 678.2 mm (laden)
Wheelbase64 inches / 1625.6 mm
Ground Clearance5.1 inches / 129.5 mm
Fuel Tank Capacity6 US gallons / 22.7 L
Wet (kerb/curb) Weight838 lbs / 380.1 kg

Infotainment

Infotainment systemSkyline™ OS
Screen Size12.3 in.
TypeFull Color TFT
Watts Per Channel125
Speakers2
Speaker SizeTwo 6.5 in. fairing speakers
AMStandard
FMStandard
SD Card, Flash Drive and MP3 – via USB ConnectionSupported
LanguagesArabic, Bahasa (Indonesian), Catalan, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (UK/USA default), Finnish, French (Canada/France), German, Hebrew, Hungarian, Indonesian, Italian, Japanese, Korean, Malay, Norwegian, Polish, Portuguese (Brazil/Portugal), Romanian, Russian, Siamese (Thai), Slovak, Spanish (Mexico/Spain), Swedish, Tagalog, Turkish, Vietnamese
Hands-free Mobile Phone – via BluetoothStandard
Voice Recognition Languages: Phone functions onlyPhone dependent
Voice Recognition Languages: Tuner/Media/NavigationDanish, English (UK/USA default), French (Canada/France), German, Italian, Spanish (Mexico/Spain), Swedish
Rider/Passenger IntercomRider and passenger headsets sold separately; VOX is available for H-D headsets
Vehicle Information Screen (Air temperature, oil pressure and EITMS)Standard
Text-to-Speech (TTS) LanguagesSame as Languages list
USBUSB-C/MTP/Smartphone will work with any phone which has proper adapters to the connection located in the inner fairing storage
Phone ConnectivityApple CarPlay (wireless or wired)
BluetoothPhone/Media Player, Headset
NavigationEmbedded Navigation standard

Rider Safety Enhancements

  • Anti-lock Brake System (ABS)
    • ABS is designed to prevent the wheels from locking under braking and helps the rider maintain control when braking in a straight-line, urgent situation.
  • Electronic Linked Braking (ELB)
    • This feature electronically applies braking effort to both wheels when the rider applies the front brake lever and, on some models when the rider applies the rear brake pedal. ELB can help many riders achieve better braking performance. It boosts braking power when needed while minimizing or stopping the linking for lighter braking or at lower speeds.
  • Traction Control System (TCS)
    • The TCS is designed to keep the rear wheel from “spinning out” when the motorcycle is accelerating in a straight line and enhances rider confidence.
  • Drag-Torque Slip Control System (DSCS)
    • DSCS is designed to reduce excessive rear-wheel slip and help prevent rear-wheel lock under powertrain-induced deceleration, which typically occurs when the rider makes an abrupt downshift gear change or quickly reduces the throttle while on wet or slippery road surfaces.
  • Vehicle Hold Control (VHC)
    • With Vehicle Hold Control (VHC), your Motorcycle’s not rolling anywhere until you’re ready to go. Perfect for hill starts or ramps, VHC keeps the brakes locked after you let go, giving you a smooth, confident launch. Just give the brake lever or pedal a quick squeeze at a stop, and VHC has you covered until you’re ready to roll. Heads up: this isn’t a parking brake replacement, but it sure makes those uphill take-offs a breeze.
  • Tire Pressure Monitoring System (TPMS)
    • TPMS alerts the rider through the information display to low or high tire air pressure. Maintaining proper tire air pressure is important both for vehicle performance and tire life.
  • Cornering Enhanced Anti-lock Brake System (C-ABS)
    • C-ABS is a variant of ABS that takes into consideration the lean angle of a two-wheel motorcycle, or the lateral acceleration of a Trike model. The brake pressure required to limit wheel slip when cornering is typically or lower than the pressure required under straight line operation.
  • Cornering Enhanced Electronic Linked Braking (C-ELB)
    • C-ELB takes into account the motorcycle lean angle or Trike lateral acceleration. C-ELB will alter the proportioning of brake pressure between the front and rear brakes when braking while cornering in an attempt to improve the ability of the Motorcycle to maintain the rider’s intended path.
  • Cornering Enhanced Traction Control System (C-TCS)
    • C-TCS is designed to prevent the rear wheel from excessive spinning under acceleration when going straight or cornering.
  • Cornering Drag-Torque Slip Control System (C-DSCS)
    • On motorcycles equipped with C-DSCS, the system helps keep the rear wheel from slipping or locking up when you quickly downshift or let off the throttle, especially on wet or slippery roads. When turning, it can adjust based on how much a two-wheel Motorcycle is leaning or the side-to-side motion on a Trike.

Harley Davidson CVO Road Glide ST (2026) Color Options

  • Black
    • Inferno Gray
    • Electric Coast
    • Citrus Heat
2026-harley-davidson-cvo-road-glide-st-2-throttlecraze.com
2026-harley-davidson-cvo-road-glide-st-3-throttlecraze.com
2026-harley-davidson-cvo-road-glide-st-1-throttlecraze.com
