The Harley-Davidson CVO Limited is the epitome of American touring luxury, boasting best-in-class power courtesy of its Twin-Cooled Milwaukee-Eight 117 engine. This refined V-Twin behemoth delivers unparalleled torque and performance, while the emulsion rear suspension with hand-adjustable pre-load ensures a plush ride.

Dual bending valve front suspension further enhances handling, allowing riders to carve through twisties with ease. The CVO Limited’s premium comfort features include heated hammock seats, remote locking luggage, and wireless headsets that pair seamlessly with the Wireless Headset Interface Module.

As you cruise down the highway, the BOOM! Box 6.5 GT infotainment system provides an unparalleled audio experience, while the custom paint scheme and luxurious finishes exude a sense of exclusivity. With its array of LED lights, color-matched split-stream air vent, and advanced security features, this bike is truly fit for royalty – and it’s only available from Harley-Davidson in 2018, making every ride an unforgettable experience that sets the standard for Grand American Touring.

Key Specifications

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 117, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Engine Capacity117 cubic inches / 1923 cc
Max Torque124.6 ft-lb / 169 nm
Fuel Tank Capacity22.7 Litres / US 6.0 gal
Weight (Wet/Kerb)944 lbs / 428 kg
Seat Height29.9 inches / 760 mm
Harley Davidson CVO Limited (2018)

All Specifications

Make & Model

ModelHarley Davidson CVO Limited
Year2018

Engine

Engine TypeFour stroke, V-Twin, Milwaukee-Eight 117, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Displacement117 cubic inches / 1923 cc
Bore x Stroke103.5 X 114.3 mm
Compression Ratio10.2:1
Max Torque124.6 ft-lb / 169 nm
Engine Management SystemElectronic Sequential Port Fuel Injection
Lubrication SystemPressurized, dry-sump with oil cooler
Cooling SystemAir cooled
ExhaustDual, with crossover

Performance

Top Speedn/a

Transmission

Gearbox6 Speed
Gear Ratios1st 9.593 2nd 6.65 3rd 4.938 4th 4 5th 3.407 6th 2.875
Final DriveBelt

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Front SuspensionShowa dual bending valve front suspension
Rear SuspensionEmulsion rear suspension with hand-adjustable pre-load
Rake26
Trail170 mm / 6.7 in

Wheels & Brakes

Front Wheel/Rim SizeGloss Black and Contrast Chrome Slicer
Front Tire Size130/80B17 65H
Rear Wheel/Rim SizeGloss Black and Contrast Chrome Slicer
Rear Tire Size180/65B16 81H
Front BrakesCaliper Type 32 mm, 4-piston fixed
Rear BrakesCaliper Type 32 mm, 4-piston fixed

Dimension & Weights

Seat Height29.9 inches / 760 mm
Wheelbase64.0 inches / 1625 mm
Ground Clearance125 mm / 4.9 in
Fuel Tank Capacity22.7 Litres / US 6.0 gal
Wet (kerb/curb) Weight944 lbs / 428 kg
Dry Weight411 kg / 906 lbs

Features

  • Emulsion rear suspension with hand-adjustable pre-load
  • Twin-Cooled Milwaukee-Eight 117 engine
  • Dual bending valve front suspension
  • Hand-adjusted preload on rear suspension
  • Colour-matched split-stream air vent
  • Tour-Pak carrier LED bezel
  • LED indicators
  • LED lighting surround
  • Custom seat cover, insert and stitching
  • Wireless headsets with Wireless Headset Interface Module
  • Integrated security system with power-locking fob
  • Tire pressure monitoring system
  • Premium heated hammock seats
  • Remote locking luggage
  • Showa dual bending valve front suspension
  • Milwaukee-Eight Twin-Cooled 117 Engine
  • Custom Touring Style paint scheme
  • High-Performing Front and Rear Suspension
