The Gas Gas SM 515 FSE is a trail bike designed for navigating demanding off-road terrain with agility and precision.
Key features include a fuel-injected, two-stroke engine displacing 510cc, producing 60 horsepower at 8000 rpm, mated to a five-speed transmission.
This powerplant lends itself well to technical sections where high revs are necessary to navigate tight corners or steep inclines.
The bike’s frame is made from chromoly steel and features a long-travel suspension system with compression and rebound adjustment on both ends. The end result is a machine capable of handling the most challenging terrain.
With its lightweight design, responsive power delivery, and precise handling, the Gas Gas SM 515 FSE is an ideal choice for experienced riders seeking to tackle the toughest trails.
Key Specifications
Engine Type
Four stroke, single cylinder, DOHC, 4 valve
Engine Capacity
31.4 cubic inches / 515 cc
Fuel Tank Capacity
2.5 US gallons / 8.5 L
Seat Height
35.4 inches / 900 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Gas Gas SM 515 FSE
Year
2008 –
Engine
Engine Type
Four stroke, single cylinder, DOHC, 4 valve
Displacement
31.4 cubic inches / 515 cc
Bore x Stroke
100 x 63 mm
Engine Management System
Magneti Marelli Injection
Lubrication System
Wet sump
Cooling System
Liquid cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Multi disc in oil bath, hydraulically operated.
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric & Kick
Chassis & Suspension
Frame Type
Deltabox built with elliptic profile CR / Mo tubing.
Front Suspension
45mm Marzocchi forks
Front Suspension Travel
11.6 inches / 295 mm
Rear Suspension
Progressive system with hlins shock absorber
Rear Suspension Travel
12.6 inches / 320 mm
Wheels & Brakes
Front Tire Size
120/80 -17
Rear Tire Size
140/80 -17
Front Brakes
Single 260mm disc 2 piston caliper
Rear Brakes
Single 220mm disc 1 piston caliper
Dimension & Weights
Seat Height
35.4 inches / 900 mm
Wheelbase
58.1 inches / 1475 mm
Ground Clearance
290 mm / 11.4 in
Fuel Tank Capacity
2.5 US gallons / 8.5 L
Dry Weight
118 kg / 260 lbs
