The Ducati XDiavel S embodies the perfect blend of cruiser and sportbike DNA, marrying the laid-back essence of a traditional cruiser with the unbridled excitement of a high-performance Italian thoroughbred.
Its twin-cylinder Testastretta DVT 1262 engine is the heartbeat of this extraordinary motorcycle, delivering an unprecedented 156 horsepower and 13.1 kgm of torque at just 5,000 rpm – making it the ultimate companion for both long journeys and spirited twisties.
With its forward-positioned footpegs and low-slung riding position, the XDiavel S invites you to sit back, relax, and soak up the scenery. Yet, with its advanced electronics and agile handling, it’s always ready to unleash a thrilling adrenaline rush whenever you crave one.
The result is an unforgettable ride experience that defies categorization – neither purely cruiser nor sportsbike, but something entirely new and uniquely Ducati.
Key Specifications
Engine Type
Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90 L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark
Engine Capacity
1262 cc / 77 cu in
Max Torque
95 ft-lb / 128.9 nm
Fuel Tank Capacity
4.75 US gallons / 18.0 L
Weight (Wet/Kerb)
545 lbs / 247 kg
Seat Height
29.7 inches / 755 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Ducati XDiavel S
Year
2019 – 2020
Engine
Engine Type
Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90 L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark
Single shock absorber, adjustable preload and rebound, remote reservoir. Single sided cast/trellis frame swingarm, natural anodized and brushed swingarm
Rear Suspension Travel
4.33 inches / 110 mm
Rake
30º
Trail
130 mm / 5.1 in
Wheels & Brakes
Front Wheel/Rim Size
Light alloy, cast, 3.50 x 17
Front Tire Size
120/70 ZR17 Pirelli Diablo Rosso II
Rear Wheel/Rim Size
Light alloy, cast, 8.00 x 17
Rear Tire Size
240/45 ZR17 Pirelli Diablo Rosso II
Front Brakes
2x 320 mm semifloating discs, radial Brembo monobloc 4-piston M4-32 callipers and radial master cylinder
Rear Brakes
Single 265 mm disc, 2-piston floating calliper
ABS
BOSCH cornering ABS as standard equipment
Dimension & Weights
Seat Height
29.7 inches / 755 mm
Wheelbase
63.6 inches / 1615 mm
Fuel Tank Capacity
4.75 US gallons / 18.0 L
Wet (kerb/curb) Weight
545 lbs / 247 kg
Dry Weight
220 kg / 485 lbs
Features
13.1 kgm maximum torque at 5,000 rpm
156 hp maximum power
Ducati Testastretta DVT 1262 engine
Desmodromic Variable Timing (DVT) system
Increased engine displacement
Water pump relocated inside the intra-cylinder V
4 different footrest positions
5 different seats
3 different handlebars
Regular seat and comfort seat with backrest as standard equipment for passenger
Ergonomic configurations for rider: 60 options
Maximum attainable lean angle: 40 degrees
Frame, suspension, brakes, and chassis set-up designed for sports-style riding fun
