The Ducati XDiavel S is a Technocruiser that defies conventions, blending the best of both worlds to create a unique riding experience. Its sleek, low-slung design is unmistakably Cruiser-inspired, yet infused with cutting-edge technology and Ducati’s signature DNA. At its heart lies the potent 1262cc Testastretta DVT engine, which delivers a kaleidoscope of torque and power that’s both exhilarating and addictive.
This powerhouse of an engine is perfectly balanced by a sophisticated chassis that exudes elegance and refinement. The XDiavel S’s futuristic aesthetic is not just about style; every element, from the headlamp to the tailpiece, has been carefully crafted to create a harmonious whole that’s greater than the sum of its parts.
Whether you’re carving up twisties or cruising down the highway, the XDiavel S promises an unforgettable ride. Its potent engine and agile handling make it equally at home on both paved roads and dirt trails, while its advanced technology ensures you stay connected to your machine like never before.
The result is a motorcycle that’s truly greater than the sum of its parts – a Technocruiser that combines heart-stopping performance with sublime sophistication.
Key Specifications
Engine Type
Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90 L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark
Engine Capacity
1262 cc / 77 cu in
Max Torque
95 ft-lb / 128.9 nm
Fuel Tank Capacity
4.75 US gallons / 18.0 L
Weight (Wet/Kerb)
545 lbs / 247 kg
Seat Height
29.7 inches / 755 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Ducati XDiavel S
Year
2017 – 2018
Engine
Engine Type
Four stroke, Testastretta DVT (Desmodromic Variable Timing), 90 L-Twin, 4 Desmodromically actuated valves per cylinder, dual spark
Single shock absorber, adjustable preload and rebound, remote reservoir. Single sided cast/trellis frame swingarm, natural anodized and brushed swingarm
Rear Suspension Travel
4.33 inches / 110 mm
Rake
30º
Trail
130 mm / 5.1 in
Wheels & Brakes
Front Wheel/Rim Size
Light alloy, cast, 3.50 x 17
Front Tire Size
120/70 ZR17 Pirelli Diablo Rosso II
Rear Wheel/Rim Size
Light alloy, cast, 8.00 x 17
Rear Tire Size
240/45 ZR17 Pirelli Diablo Rosso II
Front Brakes
2x 320 mm semifloating discs, radial Brembo monobloc 4-piston M4-32 callipers and radial master cylinder
Rear Brakes
Single 265 mm disc, 2-piston floating calliper
ABS
BOSCH cornering ABS as standard equipment
Dimension & Weights
Seat Height
29.7 inches / 755 mm
Wheelbase
63.6 inches / 1615 mm
Fuel Tank Capacity
4.75 US gallons / 18.0 L
Wet (kerb/curb) Weight
545 lbs / 247 kg
Dry Weight
220 kg / 485 lbs
Features
Modern lines and technologically advanced components
Cruiser world-inspired design
Unique silhouette
Ducati Testastretta DVT 1262 engine
Intra-cylinder L design, hallmark of every Ducati
Clean and elegant overall layout
Trellis frame
Steel teardrop tank
Ultra-modern headlamp with DRL
Tailpiece and silencer designed for harmony and balance
Matte black (Dark Stealth) or gloss black (Thrilling Black) paint schemes
Red trim on the XDiavel S version
Gloss black engine covers on the XDiavel S
Machined belt covers to show aluminium on the XDiavel S
Relaxed riding position inspired by Cruiser design
Adjustable footpegs with three positions (+/- 22.5 mm)
Modular ergonomics for a tailored fit
Ducati’s long-standing trademark color: red
