The Ducati Panigale V4 S (2020) is a beast of a motorcycle that embodies the very essence of Italian engineering and design. At its heart lies the Four-Stroke Desmosedici Stradale 90 V4 engine, boasting rearward-rotating crankshaft and four Desmodromically actuated valves per cylinder.
Its ride-by-wire system is paired with variable length intake system, ensuring a seamless power delivery that’s nothing short of exhilarating. The Panigale V4 S is equipped with top-notch suspension, featuring the Hlins NIX30 43 mm fully adjustable fork and Ohlins TTX36 unit.
The bike’s arsenal includes advanced safety features like Bosch Cornering ABS EVO and Ducati Traction Control (DTC) EVO 2. The digital instrument cluster boasts a high-resolution 5″ TFT display, while the Ducati Quick Shift (DQS) up/down EVO 2 allows for seamless gear shifting.
A true track-day warrior, the Panigale V4 S is designed to deliver unparalleled performance and handling capabilities, making it an absolute must-ride for enthusiasts of all levels. With its razor-sharp reflexes, exceptional acceleration, and razor-sharp styling, this Italian stallion is set to dominate the roads.
Key Specifications
Engine Type
Four stroke, Desmosedici Stradale 90 V4, rearward-rotating crankshaft, 4 Desmodromically actuated valves per cylinder
Engine Capacity
1103 cc / 67.3 cu in
Max Power
157.5 kw / 214 hp
Max Torque
91.5 ft-lb / 124.0 nm
Fuel Tank Capacity
4.3 US gallons / 16.0 L
Weight (Wet/Kerb)
430 lbs / 195 kg
Seat Height
32.9 inches / 835 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Ducati Panigale V4 S
Year
2020
Engine
Engine Type
Four stroke, Desmosedici Stradale 90 V4, rearward-rotating crankshaft, 4 Desmodromically actuated valves per cylinder
Displacement
1103 cc / 67.3 cu in
Bore x Stroke
81 x 53.5 mm
Compression Ratio
14.0:1
Max Horsepower
157.5 kw / 214 hp
Max Torque
91.5 ft-lb / 124.0 nm
Engine Management System
Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies. Variable length intake system
Cooling System
Liquid cooled
Exhaust
4-2-1-2 system, with 2 catalytic converters and 2 lambda probes
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch
Aluminum alloy “Front Frame” with optimized stiffnesses
Front Suspension
hlins NIX30 43 mm fully adjustable fork with TiN treatment. Electronic compression and rebound damping adjustment with hlins Smart EC 2.0 event-based mode
Rear Suspension
Fully adjustable Ohlins TTX36 unit. Electronic compression and rebound damping adjustment with hlins Smart EC 2.0 event-based mode. Aluminium single-sided swingarm
Rake
24.5
Trail
100 mm / 3.9 in
Wheels & Brakes
Front Wheel/Rim Size
3-spoke forged aluminium alloy 3.50″ x 17″
Front Tire Size
120/70 ZR17Pirelli Diablo Supercorsa SP
Rear Tire Size
200/60 ZR17 Pirelli Diablo Supercorsa SP
Front Brakes
2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema (M4.30) 4-piston callipers with Bosch Cornering ABS EVO
Rear Brakes
Single245 mm disc, 2-piston calliper with Bosch Cornering ABS EVO
Dimension & Weights
Seat Height
32.9 inches / 835 mm
Wheelbase
57.8 inches / 1469 mm
Fuel Tank Capacity
4.3 US gallons / 16.0 L
Wet (kerb/curb) Weight
430 lbs / 195 kg
Dry Weight
174 kg / 384 lbs
Features
Here is the list of key features:
90° Desmosedici Stradale V4 engine
Rearward-rotating crankshaft
4 Desmodromically actuated valves per cylinder
Electronic fuel injection system
Twin injectors per cylinder
Ride-by-wire elliptical throttle bodies
Variable length intake system
4-2-1-2 exhaust system with catalytic converters and lambda probes
Hydraulically controlled slipper clutch
6-speed gearbox with specific ratios
Aluminum alloy “Front Frame” with optimized stiffnesses
Hlins NIX30 43mm fully adjustable fork
Electronic compression and rebound damping adjustment
Ohlins TTX36 fully adjustable unit
Aluminium single-sided swingarm
Brembo Monobloc Stylema callipers with Bosch Cornering ABS EVO
Riding Modes, Power Modes, Cornering ABS EVO, DTC EVO, DWC EVO, DSC, EBC EVO
Ducati Power Launch (DPL), Ducati Quick Shift (DQS) up/down EVO 2
Full LED lighting with Daytime Running Light (DRL)
Ducati Electronic Suspension (DES) EVO with Ohlins suspension and steering damper
Lithium-ion battery, Auto-off indicators
Marchesini aluminium forged wheels
Racing style handle grips
