Ducati Multistrada 950 (2017)

The Ducati Design Center’s vision for the Multistrada 950 was to craft a compact, visually stunning bike that embodies the essence of its larger siblings.

The result is a perfect blend of design cues from the Multistrada 1200 and Enduro, with the distinctive headlight, ‘beak’, adjustable screen, two wings, and tank taking center stage. The rider’s seat and passenger accommodations have been carefully optimized for comfort, while the rear grab rail and exhaust design add a touch of sophistication.

With its classic Multistrada lines, the 950 exudes a sense of adventure and exploration, inviting riders to hit the open road. Whether tackling twisties or long-distance touring, this bike is poised to deliver an unforgettable experience. The Multistrada 950 is ready to unleash its full potential on your next ride.

Key Specifications

Engine Type	Testastretta, L-Twin cylinder, 4 valves per cylinder, Desmodromic
Engine Capacity	937 cc / 57.2 cu in
Max Power	83.1 kw / 113 hp
Max Torque	96.2 Nm / 9.8 kgf-m / 71 lb-ft @ 7750 rpm
Fuel Tank Capacity	20 L / 5.3 US gal / 4.4 Imp gal
Weight (Wet/Kerb)	500 lbs / 227 kg

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Ducati Multistrada 950
Year	2017

Engine

Engine Type	Testastretta, L-Twin cylinder, 4 valves per cylinder, Desmodromic
Displacement	937 cc / 57.2 cu in
Bore x Stroke	94 x 67.5 mm
Compression Ratio	12.6:1
Max Horsepower	83.1 kw / 113 hp
Max Torque	96.2 Nm / 9.8 kgf-m / 71 lb-ft @ 7750 rpm
Engine Management System	Fuel injection Bosch electronic fuel injection system, cylindrical throttle bodies with Ride-by-Wire, diameter 53 mm
Cooling System	Liquid cooled
Exhaust	Stainless steel muffler with catalytic converter and 2 lambda probes, single stainless steel muffler, Euro 4 compliant

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on overrun
Gearbox	6-Speed
Primary Drive Ratio	1.84:1
Gear Ratios	1st 37:15 / 2nd 30:17 / 3rd 28:20 / 4th 26:22 / 5th 24:23 / 6th 23:24
Final Drive	Chain

Electrical & Electronics System

Starter	Electric
Instrumentation	LCD, Ducati electronics Riding Modes, Power Modes, Ducati Safety Pack (ABS + DTC)

Chassis & Suspension

Frame Type	Tubular steel trellis frame
Front Suspension	KYB 48 mm fully adjustable upside-down forks
Rear Suspension	Fully adjustable Sachs monoshock unit, temote spring preload adjustment, aluminium doublesided swingarm
Rake	25.2o
Trail	105.7 mm / 4.16 in

Wheels & Brakes

Front Tire Size	120/70 – R19, Pirelli Scorpion Trail II
Rear Tire Size	170/60 – R17, Pirelli Scorpion Trail II
Front Brakes	2 x 320 mm Semi-floating discs, radially mounted monoblocco Brembo callipers, 4-piston, 2-pad, ABS standard
Rear Brakes	Single 265 mm Disc, 2-piston floating calliper, ABS standard

Dimension & Weights

Wheelbase	62.8 inches / 1594 mm
Fuel Tank Capacity	20 L / 5.3 US gal / 4.4 Imp gal
Wet (kerb/curb) Weight	500 lbs / 227 kg
Dry Weight	204 kg / 450lbs

Features

Compact, eye-pleasing design inspired by Multistrada 1200 and Multistrada 1200 Enduro
Adjustable screen
Distinctive headlight with LED daytime running lights
‘Beak’ front fairing
Two wings on the side
Tank with Ducati Red or Star White Silk color schemes
Matt grey frame and wheels
Ergonomic handlebars for optimal comfort and control
Rubber-lined foot pegs to reduce vibration
Generous seat height of 840 mm, with optional lower (820 mm) and higher (860 mm) seats available
Spacious stowage area under the passenger seat
Rear grab rail
Passenger seat
Integrated pannier supports on rear sub-frame
New switchgear for improved ergonomics and practicality
Aluminium rear sub-frame with integrated pannier supports
Frame designed to maximize efficiency in terms of both weight and performance
Carefully designed alloy wheels with thin Y-spokes that resemble wire spokes
