The Ducati Multistrada 1260 is a revolution in versatility and performance. Its new Testastretta DVT engine boasts a 1262cc displacement, delivering ample low-to-mid range torque for effortless rideability.
With its sleek design and lighter, sportier wheels, the Multistrada exudes an air of sophistication. The latest Ride-by-Wire system ensures smoother throttle control, while the Ducati Quick Shift (DQS) Up & Down feature simplifies gear shifting, allowing riders to focus on the road ahead.
At its core, the Multistrada 1260 is a testament to Ducati’s commitment to innovation and rider comfort. This machine redefines the touring experience with its advanced electronics, improved ergonomics, and unparalleled performance capabilities.
The Multistrada 1260 sets a new standard for versatility, delivering unmatched power and control in all riding conditions – making it an exhilarating adventure for riders of all skill levels.
Key Specifications
Engine Type
Four stroke, 90 L twin cylinders,Testastretta DVT with Desmodromic Variable Timing, DOHC, 4 valves per cylinder
Engine Capacity
77.0 cubic inches / 1262 cc
Max Power
156 hp / 116.2 kW @ 9500 rpm
Max Torque
96.2 ft-lb / 130 nm
Fuel Tank Capacity
5.3 US gallons / 20.0 L
Weight (Wet/Kerb)
511 lbs / 232 kg
Seat Height
32.5 inches / 825 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Ducati Multistrada 1260
Year
2020
Engine
Engine Type
Four stroke, 90 L twin cylinders,Testastretta DVT with Desmodromic Variable Timing, DOHC, 4 valves per cylinder
Displacement
77.0 cubic inches / 1262 cc
Bore x Stroke
106 x 71,5 mm
Compression Ratio
13.0:1
Max Horsepower
156 hp / 116.2 kW @ 9500 rpm
Max Torque
96.2 ft-lb / 130 nm
Engine Management System
Bosch electronic fuel injection system, elliptical throttle bodies with Ride-by-Wire, equivalent diameter 56 mm
Lubrication System
Wet sump
Cooling System
Liquid cooled
Exhaust
Stainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Gearbox
6 Speed
Gear Ratios
1=37/15 2=30/17 3=27/20 4=24/22 5=23/24 6=22/25
Final Drive
Chain; Front sprocket 15; Rear sprocket 40
Electrical & Electronics System
Starter
Electric
Instrumentation
LCD
Chassis & Suspension
Frame Type
Tubular steel trellis frame
Front Suspension
48 mm fully adjustable USD forks.
Front Suspension Travel
6.7 inches / 170 mm
Rear Suspension
Fully adjustable Sachs monoshock unit. Remote spring preload adjustment. Aluminium single-sided swing-arm.
Rear Suspension Travel
6.7 inches / 170 mm
Rake
24
Trail
109 mm / 4.3 in
Wheels & Brakes
Front Wheel/Rim Size
5-spoke Y-shape cast light alloy 3.50″ x 17″
Front Tire Size
120/70 R17 Pirelli Scopion Trail II
Rear Wheel/Rim Size
5-spoke Y-shaped cast light alloy 6.00″ x 17″
Rear Tire Size
190/55 R17Pirelli Scorpion Trail II
Front Brakes
2 x 320 mm semi-floating discs, radially mounted monobloc Brembo callipers, 4-piston, 2-pad, with cornering ABS as standard equipment
Rear Brakes
Single265 mm disc, 2-piston floating calliper, with cornering ABS as standard equipment
