The Ducati Multistrada 1200S Granturismo is the ultimate premium touring machine, boasting a range of enhancements that set it apart from its siblings in the Multistrada lineup.

Its 1198cc, 90-degree L-twin engine produces a potent blend of power and character, with a rich sound and smooth delivery that’s perfectly suited to long-distance riding. The DOHC architecture and desmodromic valve actuation system ensure incredible refinement and responsiveness.

The Multistrada 1200S Granturismo is equipped with a host of innovative features, including a multifunction digital dashboard and an interface for managing Riding Modes, which allow riders to tailor their bike’s behavior to suit their style. With its advanced electronics and premium appointments, this tourer offers an unparalleled riding experience that’s both exhilarating and comfortable.

The result is a machine that’s perfectly poised to tackle the world’s most epic routes with confidence and poise, making it the ultimate travel companion for adventurous riders.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder
Engine Capacity73.1 cubic inches / 1198.4 cc
Max Power110.3 kw / 150 hp
Max Torque124.5 Nm / 12.7 kgm / 91.8 lb-ft @ 7500rpm
Fuel Tank Capacity5.3 US gallons / 20.0 L
Weight (Wet/Kerb)485 lbs / 220 kg
Seat Height33.4 inches / 850 mm
Ducati Multistrada 1200SGranturismo (2014)

All Specifications

Make & Model

ModelDucati Multistrada 1200SGranturismo
Year2014

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder
Displacement73.1 cubic inches / 1198.4 cc
Bore x Stroke106 x 67.9 mm
Compression Ratio11.5:1
Max Horsepower110.3 kw / 150 hp
Max Torque124.5 Nm / 12.7 kgm / 91.8 lb-ft @ 7500rpm
Engine Management SystemMitsubishi electronic fuel injection system, Mikuni elliptical throttle bodies
Lubrication SystemWet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Cooling SystemLiquid cooled
ExhaustStainless steel muffler with catalytic converter and 2 lambda probes, alluminium tail pipes

Performance

Top Speedn/a

Transmission

ClutchLight action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Gearbox6 Speed
Gear Ratios1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th 24/22 / 5th 23/24 / 6th 22/25
Final DriveChain #530, front sprocket 15; rear sprocket 40

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel trellis frame
Front SuspensionSachs 48 mm fully adjustable USD forks. Electronic compression and rebound damping adjustment with Ducati Skyhook Suspension
Front Suspension Travel6.7 inches / 170 mm
Rear SuspensionProgressive linkage with fully adjustable Sachs monoshock. Electronic compression and rebound damping adjustment. Electronic spring preload with DSS aluminium single-sided swingarm
Rear Suspension Travel6.7 inches / 170 mm
Rake25
Trail110 mm / 4.33 in

Wheels & Brakes

Front Wheel/Rim Size10-spoke light alloy, 3.50 x 17
Front Tire Size120/70 – ZR17
Rear Wheel/Rim Size10-spoke light alloy, 6.00 x 17
Rear Tire Size190/55 – ZR17
Front Brakes2 x 320 mm Semi-floating discs, radially mounted Brembo calipers, 4-piston, 2-pad. ABS as standard equipment
Rear BrakesSingle 245 mm disc, 2-piston caliper

Dimension & Weights

Overall Length2200 mm / 86.6 in
Overall Width945 mm / 37.2 in
Overall Height1310 mm / 51.5 in
Seat Height33.4 inches / 850 mm
Wheelbase60.2 inches / 1530 mm
Fuel Tank Capacity5.3 US gallons / 20.0 L
Wet (kerb/curb) Weight485 lbs / 220 kg
Dry Weight192 kg / 423 lbs

Features

  • Four stroke, 90 L twin cylinder engine
  • DOHC desmodromic 4 valves per cylinder
  • Mitsubishi electronic fuel injection system
  • Mikuni elliptical throttle bodies
  • Multifunction digital dashboard with two displays and white backlight
  • Main LCD display with odometer, speedometer, rev counter, clock, gear indicator, coolant temperature, and fuel level
  • Circular LCD dot-matrix display for trip computer and maintenance intervals
  • Interface for Riding Modes (power curve and throttle response control)
  • Traction control and ABS
  • Oil pressure warning light
  • Neutral N warning light
  • Fuel warning light
  • Turn signal indicators
  • EOBD diagnosis light
  • High beam indicator
  • DTC intervention light (Traction Control)
  • Immobilizer deterrent
  • Auto headlight control with auto switching-off during engine start and after 60 seconds from Key-On without starting the engine
  • Ducati Performance Comfort Seat
  • Backrest built into top-case for passenger
  • Extra 20mm bar-risers for more upright riding position
  • Extended screen for added wind-protection
  • Pirelli Angel GT tyres
  • Engine protection bars in tubular steel
  • Additional LED aluminium-cased spot-lights with dedicated switch on left-hand handlebar
