Ducati Multistrada 1200S Touring Granturismo (2013)

Ducati Multistrada 1200S Touring Granturismo (2013)

The Ducati Multistrada 1200S Touring Granturismo is the pinnacle of premium touring motorcycles, boasting a wealth of enhancements and features that set it apart from its counterparts. The heart of this machine is the 90° L-twin cylinder engine, delivering its signature Ducati Desmodromic valve train to produce an exhilarating power-to-weight ratio.

The Multistrada’s multifunction digital dashboard is a masterpiece of design and functionality, providing riders with instant access to vital information through two clear LCD displays. The interface for Riding Modes allows control over the bike’s behaviour, including traction control and ABS settings, while the addition of Ducati Performance Comfort Seat and passenger backrest elevate comfort levels for both rider and pillion.

With a host of thoughtful design touches, including three weatherproof interior soft-bags, side-luggage capacity increased to 73 litres, and a standard 48-litre top-case, the Multistrada 1200S Touring Granturismo is poised to conquer even the most epic road trips with unbridled style and capability.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder
Engine Capacity73.1 cubic inches / 1198.4 cc
Max Power110.3 kw / 150 hp
Max Torque124.5 Nm / 12.7 kgm / 91.8 lb-ft @ 7500rpm
Fuel Tank Capacity5.3 US gallons / 20.0 L
Weight (Wet/Kerb)516 lbs / 234 kg
Seat Height33.4 inches / 850 mm
Ducati Multistrada 1200S Touring Granturismo (2013)

All Specifications

Make & Model

ModelDucati Multistrada 1200S Touring Granturismo
Year2013

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder
Displacement73.1 cubic inches / 1198.4 cc
Bore x Stroke106 x 67.9 mm
Compression Ratio11.5:1
Max Horsepower110.3 kw / 150 hp
Max Torque124.5 Nm / 12.7 kgm / 91.8 lb-ft @ 7500rpm
Engine Management SystemMitsubishi electronic fuel injection system, Mikuni elliptical throttle bodies
Lubrication SystemWet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Cooling SystemLiquid cooled
ExhaustStainless steel muffler with catalytic converter and 2 lambda probes, alluminium tail pipes

Performance

Top Speed233 km/h / 145 mph

Transmission

ClutchLight action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Gearbox6 Speed
Gear Ratios1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th 24/22 / 5th 23/24 / 6th 22/25
Final DriveChain #530, front sprocket 15; rear sprocket 40

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel trellis frame
Front SuspensionSach 48 mm fully adjustable USD forks. Electronic compression and rebound damping adjustment with Ducati Skyhook Suspension
Front Suspension Travel6.7 inches / 170 mm
Rear SuspensionProgressive linkage with fully adjustable hlins monoshock. Electronic compression and rebound damping adjustment. Electronic spring preload with DSS aluminium single-sided swingarm
Rear Suspension Travel6.7 inches / 170 mm
Rake25
Trail110 mm / 4.33 in

Wheels & Brakes

Front Wheel/Rim Size10-spoke light alloy, 3.50 x 17
Front Tire Size120/70 – ZR17
Rear Wheel/Rim Size10-spoke light alloy, 6.00 x 17
Rear Tire Size190/55 – ZR17
Front Brakes2 x 320 mm Semi-floating discs, radially mounted Brembo calipers, 4-piston, 2-pad. ABS as standard equipment
Rear BrakesSingle 245 mm disc, 2-piston caliper

Dimension & Weights

Overall Length2200 mm / 86.6 in
Overall Width945 mm / 37.2 in
Overall Height1310 mm / 51.5 in
Seat Height33.4 inches / 850 mm
Wheelbase60.2 inches / 1530 mm
Fuel Tank Capacity5.3 US gallons / 20.0 L
Wet (kerb/curb) Weight516 lbs / 234 kg
Dry Weight206kg / 454 lbs

Features

  • Four stroke, 90 L twin cylinder engine
  • DOHC, desmodromic 4 valves per cylinder
  • Mitsubishi electronic fuel injection system
  • Mikuni elliptical throttle bodies
  • Multifunction digital dashboard with two displays and white backlight
  • Main LCD display: odometer, speedometer, rev counter, clock, gear indicator, coolant temperature, fuel level
  • Circular LCD dot-matrix display: trip computer, maintenance intervals, signaling alarms and errors detection (diagnosis)
  • Interface for Riding Modes control power curve and throttle response power, traction control, ABS
  • “Parking” and “Steering lock” indicators
  • Oil pressure warning light
  • Neutral N indicator
  • Fuel warning light
  • Turn signal lights
  • EOBD (diagnosis) light
  • High beam light
  • DTC intervention (Traction Control) and deterrent immobilizer
  • Ducati Performance Comfort Seat
  • 48 litre top-case as standard equipment
  • Three weatherproof interior soft-bags for cargo removal
  • Pirelli Angel GT tyres
  • Engine protection bars in tubular steel
  • Additional LED aluminium-cased spot-lights
