The Multistrada 1200S DVT Pikes Peak is an uncompromising adventure touring machine that embodies the essence of Ducati’s innovative spirit. Equipped with the Testastretta DVT engine, this bike boasts a perfect blend of power, torque, and fluidity, courtesy of its double variable valve timing system.
Its sleek design features a 19-inch front wheel shod with knobby tires, a skid plate, and a high-mounted exhaust can, making it an off-road capable motorcycle like no other. The premium equipment list includes a full-TFT instrument panel, Bosch 9ME multi-calibration cornering ABS, and Ducati Safety Pack.
From the moment you hit the throttle, the Multistrada 1200S DVT Pikes Peak comes alive with its razor-sharp handling and intuitive ride-by-wire system. The high-performance specifications, including a fully adjustable Hylus fork and TTX36 rear shock, ensure that this bike is ready to tackle even the toughest terrain.
With its concentration of innovations, advanced technology, and refined style, the Multistrada 1200S DVT Pikes Peak redefines the boundaries of adventure touring motorcycles.
Key Specifications
Engine Type
Four stroke, 90 L twin cylinders,Testastretta DVT with Desmodromic Variable Timing, DOHC, 4 alves per cylinder
Engine Capacity
1198.4 cc / 73.1 in-in cc /73.1 in-in
Max Power
117.7 kw / 160 hp
Max Torque
136 Nm / 13.9 kgf-m / 100.3 lb-ft @ 7500 rpm
Fuel Tank Capacity
5.3 US gallons / 20.0 L
Weight (Wet/Kerb)
509 lbs / 231 kg
Seat Height
32.5 inches / 825 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Ducati Multistrada 1200S DVT Pikes Peak
Year
2016
Engine
Engine Type
Four stroke, 90 L twin cylinders,Testastretta DVT with Desmodromic Variable Timing, DOHC, 4 alves per cylinder
Displacement
1198.4 cc / 73.1 in-in cc /73.1 in-in
Bore x Stroke
106 x 67.9 mm
Compression Ratio
11.5:1
Max Horsepower
117.7 kw / 160 hp
Max Torque
136 Nm / 13.9 kgf-m / 100.3 lb-ft @ 7500 rpm
Engine Management System
Bosch electronic fuel injection system, elliptical throttle bodies with Ride-by-Wire, equivalent diameter 56 mm
Lubrication System
Wet sump
Cooling System
Liquid cooled
Exhaust
Stainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Ohlins 48 mm fully adjustable usd fork with TiN treatment
Front Suspension Travel
6.7 inches / 170 mm
Rear Suspension
Fully adjustable Ohlins TTX36 monoshock unit.Electronic compression and rebound damping adjustment with Ducati Skyhook suspension Evo (DSS). Aluminium single-sided swingarm
Rear Suspension Travel
6.7 inches / 170 mm
Rake
24
Trail
19 mm / 4.3 in
Wheels & Brakes
Front Wheel/Rim Size
Y-shaped 3-spoke in light alloy 3.50″ x 17″
Front Tire Size
Pirelli Scopion Trail II 120/70 R17
Rear Wheel/Rim Size
Y-shaped 3-spoke in light alloy 6.00″ x 17″
Rear Tire Size
Pirelli Scorpion Trail II 190/55 R17
Front Brakes
2 x 330 mm Semi-floating discs, radially mounted Brembo monobloc Evo M50 4-piston callipers, 2-pad, radial pump with cornering ABS as standard equipment
Rear Brakes
Single265 mm disc, 2-piston floating calliper, with cornering ABS as standard equipment
Dimension & Weights
Seat Height
32.5 inches / 825 mm
Wheelbase
60.2 inches / 1529 mm
Fuel Tank Capacity
5.3 US gallons / 20.0 L
Wet (kerb/curb) Weight
509 lbs / 231 kg
Dry Weight
208kg /458 lbs
Features
Four stroke, 90 L twin cylinders engine
Testastretta DVT with Desmodromic Variable Timing
DOHC, 4 valves per cylinder
Bosch electronic fuel injection system
Ride-by-Wire technology
Elliptical throttle bodies
56 mm equivalent diameter
Double-sided swingarm
19″ front wheel
Knobby tires
Skid plate
Higher-mounted single exhaust can
Full-TFT instrument panel
Bosch 9ME multi-calibration cornering ABS
Full-LED headlights
Multistrada Link Inertial platform
Cruise control
Hands-free ignition
Ducati Wheelie Control (DWC)
Ducati Traction Control (DTC)
