The Ducati Multistrada 1200S DVT (2016) represents the pinnacle of versatility and performance in a single motorcycle package. Its Testastretta DVT engine is a marvel of modern engineering, boasting variable valve timing that optimises power delivery throughout the rev range, ensuring maximum punch at high rpm and fluidity at low speeds.
This technological tour-de-force also features an Inertial Measurement Unit (IMU), which dynamically measures roll, yaw, and pitch angles to enhance both performance and safety. The result is a machine that excels in every riding scenario, from spirited canyon carving to long-distance touring. With its state-of-the-art electronics package, the Multistrada 1200S DVT sets a new standard for motorcycling excellence.
The Multistrada 1200S DVT’s sublime engine character and razor-sharp handling make it the ultimate riding companion, capable of effortlessly adapting to any road or terrain.
Key Specifications
Engine Type
Four stroke, 90 L twin cylinders,Testastretta DVT with Desmodromic Variable Timing, DOHC, 4 valves per cylinder
Engine Capacity
73.1 cubic inches / 1198.4 cc
Max Power
117.7 kw / 160 hp
Max Torque
136 Nm / 13.9 kgf-m / 100.3 lb-ft @ 7500 rpm
Fuel Tank Capacity
5.3 US gallons / 20.0 L
Weight (Wet/Kerb)
518 lbs / 235 kg
Seat Height
32.5 inches / 825 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Ducati Multistrada 1200S DVT
Year
2016
Engine
Engine Type
Four stroke, 90 L twin cylinders,Testastretta DVT with Desmodromic Variable Timing, DOHC, 4 valves per cylinder
Displacement
73.1 cubic inches / 1198.4 cc
Bore x Stroke
106 x 67.9 mm
Compression Ratio
11.5:1
Max Horsepower
117.7 kw / 160 hp
Max Torque
136 Nm / 13.9 kgf-m / 100.3 lb-ft @ 7500 rpm
Engine Management System
Bosch electronic fuel injection system, elliptical throttle bodies with Ride-by-Wire, equivalent diameter 56 mm
Lubrication System
Wet sump
Cooling System
Liquid cooled
Exhaust
Stainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Sachs 48 mm fully adjustable usd fork. Electronic compression and rebound damping adjustment with Ducati Skyhook suspension Evo (DSS)
Front Suspension Travel
6.7 inches / 170 mm
Rear Suspension
Fully adjustable Sachs monoshock unit.Electronic compression and rebound damping adjustment with Ducati Skyhook suspension Evo (DSS). Aluminium single-sided swingarm
Rear Suspension Travel
6.7 inches / 170 mm
Rake
24
Trail
110 mm / 4.33 in
Wheels & Brakes
Front Wheel/Rim Size
Y-shaped 3-spoke in light alloy 3.50″ x 17″
Front Tire Size
Pirelli Scopion Trail II 120/70 R17
Rear Wheel/Rim Size
Y-shaped 3-spoke in light alloy 6.00″ x 17″
Rear Tire Size
Pirelli Scorpion Trail II 190/55 R17
Front Brakes
2 x 330 mm Semi-floating discs, radially mounted Brembo monoblock Evo M50 4-piston callipers, 2-pad, radial pump with cornering ABS as standard equipment
Rear Brakes
Single265 mm disc, 2-piston floating calliper, with cornering ABS as standard equipment
