Ducati Multistrada 1200S (2014)

Ducati Multistrada 1200S (2014)

The 2014 Ducati Multistrada 1200S embodies the very essence of adventure and versatility. Its potent 90-degree L-twin engine delivers a unique blend of power and character, its smooth, progressive torque delivery making it equally at home on twisty roads or long-distance touring duties.

A sophisticated electronics package, including traction control and ABS, provides unparalleled levels of stability and rider safety. The Multistrada’s innovative Riding Modes system allows riders to tailor the bike’s behavior to suit their mood and the road conditions.

The Multistrada 1200S is equipped with a host of premium features, including stylish panniers, heated grips, and a practical centre stand, making it an ideal companion for both short trips and epic long-distance adventures.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder
Engine Capacity73.1 cubic inches / 1198.4 cc
Max Power110.3 kw / 150 hp
Max Torque124.5 Nm / 12.7 kgm / 91.8 lb-ft @ 7500rpm
Fuel Tank Capacity5.3 US gallons / 20.0 L
Weight (Wet/Kerb)485 lbs / 220 kg
Seat Height33.4 inches / 850 mm
Ducati Multistrada 1200S (2014)

All Specifications

Make & Model

ModelDucati Multistrada 1200S
Year2014

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder
Displacement73.1 cubic inches / 1198.4 cc
Bore x Stroke106 x 67.9 mm
Compression Ratio11.5:1
Max Horsepower110.3 kw / 150 hp
Max Torque124.5 Nm / 12.7 kgm / 91.8 lb-ft @ 7500rpm
Engine Management SystemMitsubishi electronic fuel injection system, Mikuni elliptical throttle bodies
Lubrication SystemWet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Cooling SystemLiquid cooled
ExhaustStainless steel muffler with catalytic converter and 2 lambda probes, alluminium tail pipes

Performance

Top Speedn/a

Transmission

ClutchLight action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Gearbox6 Speed
Gear Ratios1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th 24/22 / 5th 23/24 / 6th 22/25
Final DriveChain #530, front sprocket 15; rear sprocket 40

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel trellis frame
Front SuspensionSachs 48 mm fully adjustable USD forks. Electronic compression and rebound damping adjustment with Ducati Skyhook Suspension
Front Suspension Travel6.7 inches / 170 mm
Rear SuspensionProgressive linkage with fully adjustable Sachs monoshock. Electronic compression and rebound damping adjustment. Electronic spring preload with DSS aluminium single-sided swingarm
Rear Suspension Travel6.7 inches / 170 mm
Rake25
Trail110 mm / 4.33 in

Wheels & Brakes

Front Wheel/Rim Size10-spoke light alloy, 3.50 x 17
Front Tire Size120/70 – ZR17
Rear Wheel/Rim Size10-spoke light alloy, 6.00 x 17
Rear Tire Size190/55 – ZR17
Front Brakes2 x 320 mm Semi-floating discs, radially mounted Brembo calipers, 4-piston, 2-pad. ABS as standard equipment
Rear BrakesSingle 245 mm disc, 2-piston caliper

Dimension & Weights

Overall Length2200 mm / 86.6 in
Overall Width945 mm / 37.2 in
Overall Height1310 mm / 51.5 in
Seat Height33.4 inches / 850 mm
Wheelbase60.2 inches / 1530 mm
Fuel Tank Capacity5.3 US gallons / 20.0 L
Wet (kerb/curb) Weight485 lbs / 220 kg
Dry Weight192 kg / 423 lbs

Features

  • Four stroke, 90 L twin cylinder engine
  • DOHC, desmodromic 4 valves per cylinder
  • Mitsubishi electronic fuel injection system
  • Mikuni elliptical throttle bodies
  • Multifunction digital dashboard
  • Main LCD display: odometer, speedometer, rev counter, clock, gear indicator, coolant temperature, fuel level
  • Circular LCD dot-matrix display: trip computer, maintenance intervals indicator, alarms and errors detection (diagnosis), setup menu and customization functions
  • Interface for Riding Modes (control power curve and throttle response power, traction control, ABS)
  • “Parking” and “Steering lock” indicators
  • Oil pressure, neutral N, fuel warning, turn signal, EOBD (diagnosis), high beam lights
  • DTC intervention (Traction Control) and deterrent immobilizer (in Key-Off)
  • Headlight control: auto switching-off during engine start, auto turning-off after 60 seconds from Key-On without starting the engine
  • Ducati Skyhook Suspension (DSS)
  • Stylish panniers
  • Heated grips
  • Practical centre stand
Ducati Multistrada 1200S (2014)
Ducati Multistrada 1200S (2014)
Ducati Multistrada 1200S (2014)
Ducati Multistrada 1200S (2014)
