Ducati Multistrada 1200S (2011)

The Ducati Multistrada 1200S is a tour-de-force of engineering and design, boasting an impressive four-stroke, 90° twin cylinder engine that delivers a rich, V-twin soundtrack and plenty of torque.

Its DOHC architecture and desmodromic valve train ensure responsive power delivery, while the Mitsubishi electronic fuel injection system provides crisp throttle response.

The Multistrada’s rider-focused cockpit features a comprehensive multifunction digital dashboard with two displays, providing essential information at a glance. The interface is intuitive, allowing riders to seamlessly switch between various riding modes, which adjust the bike’s behavior to suit road conditions and personal preference.

But what truly sets this motorcycle apart is its exclusive active suspension system, which dynamically adjusts damping to maintain optimal ride quality and stability. This cutting-edge technology makes it an ideal companion for both long-distance touring and spirited on-road adventures. With its bold styling, impressive performance, and unparalleled handling capabilities, the Ducati Multistrada 1200S redefines the boundaries of what a motorcycle can achieve.

Key Specifications

Engine Type	Four stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder
Engine Capacity	73.1 cubic inches / 1198.4 cc
Max Power	110.3 kw / 150 hp
Max Torque	118.7Nm / 12.1 kgm / 87.5 lb-ft @ 7500rpm
Fuel Tank Capacity	5.3 US gallons / 20.0 L
Weight (Wet/Kerb)	485 lbs / 220 kg
Seat Height	33.4 inches / 850 mm

*n/a – information not provided by manufacturer

All Specifications

Make & Model

Model	Ducati Multistrada 1200S
Year	2011

Engine

Engine Type	Four stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder
Displacement	73.1 cubic inches / 1198.4 cc
Bore x Stroke	106 x 67.9 mm
Compression Ratio	11.5:1
Max Horsepower	110.3 kw / 150 hp
Max Torque	118.7Nm / 12.1 kgm / 87.5 lb-ft @ 7500rpm
Engine Management System	Mitsubishi electronic fuel injection system, Mikuni elliptical throttle bodies
Lubrication System	Wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Cooling System	Liquid cooled
Exhaust	Stainless steel muffler with catalytic converter and 2 lambda probes, alluminium tail pipes

Performance

Top Speed

n/a

*n/a – information not provided by manufacturer

Transmission

Clutch	Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Gearbox	6 Speed
Gear Ratios	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th 24/22 / 5th 23/24 / 6th 22/25
Final Drive	Chain #530, front sprocket 15; rear sprocket 40

Electrical & Electronics System

Starter

Electric

Chassis & Suspension

Frame Type	Tubular steel trellis frame
Front Suspension	Sach 48 mm fully adjustable USD forks. Electronic compression and rebound damping adjustment with Ducati Skyhook Suspension
Front Suspension Travel	6.7 inches / 170 mm
Rear Suspension	Progressive linkage with fully adjustable hlins monoshock. Electronic compression and rebound damping adjustment. Electronic spring preload with DSS aluminium single-sided swingarm
Rear Suspension Travel	6.7 inches / 170 mm
Rake	25
Trail	110 mm / 4.33 in

Wheels & Brakes

Front Wheel/Rim Size	10-spoke light alloy, 3.50 x 17
Front Tire Size	120/70 – ZR17
Rear Wheel/Rim Size	10-spoke light alloy, 6.00 x 17
Rear Tire Size	190/55 – ZR17
Front Brakes	2 x 320 mm Semi-floating discs, radially mounted Brembo calipers, 4-piston, 2-pad. ABS as standard equipment
Rear Brakes	Single 245 mm disc, 2-piston caliper

Dimension & Weights

Overall Length	2200 mm / 86.6 in
Overall Width	945 mm / 37.2 in
Overall Height	1310 mm / 51.5 in
Seat Height	33.4 inches / 850 mm
Wheelbase	60.2 inches / 1530 mm
Fuel Tank Capacity	5.3 US gallons / 20.0 L
Wet (kerb/curb) Weight	485 lbs / 220 kg
Dry Weight	192 kg / 423 lbs

Features

Four-stroke 90 L twin cylinder engine
DOHC (Double Overhead Camshaft) design
Desmodromic 4 valves per cylinder
Mitsubishi electronic fuel injection system
Mikuni elliptical throttle bodies
Multifunction digital dashboard with two displays and white backlight
LCD display for main functions: odometer, speedometer, rev counter, clock, gear indicator, coolant temperature, and fuel level
Circular LCD dot-matrix display for trip computer and maintenance intervals
Interface for Riding Modes (control power curve and throttle response)
Traction control system
ABS (Anti-lock Braking System)
“Parking” and “Steering lock” indicators
Oil pressure warning light
Neutral N indicator
Fuel level warning light
Turn signal lights
EOBD (diagnosis) display
High beam indicator
DTC intervention (Traction Control) indicator
Immobilizer system
