Ducati Multistrada 1200S (2010)

Ducati Multistrada 1200S (2010)

The Ducati Multistrada 1200S is a tour de force of motorcycle engineering, boasting a powerful 90° L-twin cylinder engine that pumps out an impressive 150hp. This potent powerplant is matched by a sophisticated electronics package, featuring ride-by-wire throttle control and three Riding Modes to suit varying riding styles.

The Multistrada’s multifunction digital dashboard offers two displays with white backlight, providing an abundance of information at the rider’s fingertips. Whether navigating twisties or cruising down the highway, the Ducati Multistrada 1200S is a masterclass in balance and poise.

The Multistrada’s active suspension system, borrowed from the 1098R, further enhances its ability to adapt to changing road conditions. With its advanced electronics and robust design, this bike is an absolute delight to ride – whether you’re carving up mountain roads or devouring miles on the open highway.

This is a motorcycle that redefines what’s possible in the world of adventure touring, offering an unparalleled blend of performance, comfort, and style.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder
Engine Capacity73.1 cubic inches / 1198.4 cc
Max Power110.3 kw / 150 hp
Max Torque118.7Nm / 12.1 kgm / 87.5 lb-ft @ 7500rpm
Fuel Tank Capacity5.3 US gallons / 20.0 L
Weight (Wet/Kerb)485 lbs / 220 kg
Seat Height33.4 inches / 850 mm
Ducati Multistrada 1200S (2010)

All Specifications

Make & Model

ModelDucati Multistrada 1200S
Year2010

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder
Displacement73.1 cubic inches / 1198.4 cc
Bore x Stroke106 x 67.9 mm
Compression Ratio11.5:1
Max Horsepower110.3 kw / 150 hp
Max Torque118.7Nm / 12.1 kgm / 87.5 lb-ft @ 7500rpm
Engine Management SystemMitsubishi electronic fuel injection system, Mikuni elliptical throttle bodies
Lubrication SystemWet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Cooling SystemLiquid cooled
ExhaustStainless steel muffler with catalytic converter and 2 lambda probes, alluminium tail pipes

Performance

Top Speedn/a

Transmission

ClutchLight action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Gearbox6 Speed
Gear Ratios1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th 24/22 / 5th 23/24 / 6th 22/25
Final DriveChain #530, front sprocket 15; rear sprocket 40

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel trellis frame
Front SuspensionSach 48 mm fully adjustable USD forks. Electronic compression and rebound damping adjustment with Ducati Skyhook Suspension
Front Suspension Travel6.7 inches / 170 mm
Rear SuspensionProgressive linkage with fully adjustable hlins monoshock. Electronic compression and rebound damping adjustment. Electronic spring preload with DSS aluminium single-sided swingarm
Rear Suspension Travel6.7 inches / 170 mm
Rake25
Trail110 mm / 4.33 in

Wheels & Brakes

Front Wheel/Rim Size10-spoke light alloy, 3.50 x 17
Front Tire Size120/70 – ZR17
Rear Wheel/Rim Size10-spoke light alloy, 6.00 x 17
Rear Tire Size190/55 – ZR17
Front Brakes2 x 320 mm Semi-floating discs, radially mounted Brembo calipers, 4-piston, 2-pad. ABS as standard equipment
Rear BrakesSingle 245 mm disc, 2-piston caliper

Dimension & Weights

Overall Length2200 mm / 86.6 in
Overall Width945 mm / 37.2 in
Overall Height1310 mm / 51.5 in
Seat Height33.4 inches / 850 mm
Wheelbase60.2 inches / 1530 mm
Fuel Tank Capacity5.3 US gallons / 20.0 L
Wet (kerb/curb) Weight485 lbs / 220 kg
Dry Weight192 kg / 423 lbs

Features

  • Four-stroke, 90L twin cylinder engine
  • DOHC (dual overhead camshaft) design
  • Desmodromic 4 valves per cylinder
  • Mitsubishi electronic fuel injection system
  • Mikuni elliptical throttle bodies
  • Multifunction digital dashboard with two displays and white backlight
  • Main LCD display: odometer, speedometer, rev counter, clock, gear indicator, coolant temperature, fuel level
  • Circular LCD dot-matrix display: trip computer, maintenance intervals indicator, signaling alarms and errors detection (diagnosis), setup menu, customization functions
  • Interface for Riding Modes management
  • Traction control system
  • ABS (Anti-lock Braking System)
  • Oil pressure warning light
  • Neutral N warning light
  • Fuel warning light
  • Turn signal lights
  • EOBD (diagnosis) system
  • High beam light
  • DTC (Traction Control) intervention indicator
