Ducati Monster S2R 800 (2006)

Ducati Monster S2R 800 (2006)

The Ducati Monster S2R 800: a street fighter born for the most demanding roads and tracks. Its 90-degree V-twin engine roars to life with a distinctive Desmodromic soundtrack, unleashing its fury through two valves per cylinder under the watchful eye of a SOHC head.

This potent package is matched by an equally impressive set of hardware: aluminium alloy single-sided trellis swingarm, progressive rear suspension, 5-spoke wheels, and massive tyres for added grip. But it’s not just about raw power – the S2R also boasts an exclusive APTC clutch system, ensuring maximum safety on even the most hair-raising descents.

With its fully exposed engine and minimalist bodywork, the Monster S2R embodies the perfect fusion of style and substance: a true motorcycling icon that defies imitation. And for those who crave even more, Ducati’s Performance Accessories catalogue is included with every bike, offering endless possibilities to customise and enhance your ride.

Key Specifications

Engine TypeFour stroke, 90 Lt win cylinder, SOHC, desmodromic 2 valves per cylinder.
Engine Capacity803 cc / 49.0 cu in
Max Power56.7 kw / 77 hp
Max Torque73 Nm / 7.4 kgf-m / 54 ft-lbs @ 6500 rpm
Fuel Tank Capacity3.6 US gallons / 14.0 L
Ducati Monster S2R 800 (2006)

All Specifications

Make & Model

ModelDucati Monster S2R 800
Year2006

Engine

Engine TypeFour stroke, 90 Lt win cylinder, SOHC, desmodromic 2 valves per cylinder.
Displacement803 cc / 49.0 cu in
Bore x Stroke88 x 66 mm
Compression Ratio10.5:1
Max Horsepower56.7 kw / 77 hp
Max Torque73 Nm / 7.4 kgf-m / 54 ft-lbs @ 6500 rpm
Engine Management SystemFuel injection, 45 mm throttle body
Cooling SystemAir cooled
Exhaust2-1-2, High

Performance

Top Speed205.8 km/h / 127.9 mph

Transmission

ClutchAPTC wet multiplate with hydraulic control
Gearbox6 Speed
Gear Ratios1st 32/13, 2nd 30/18, 3rd 28/21, 4th 26/23, 5th 22/22, 6th 24/26
Final DriveChain; Front sprocket 15; Rear sprocket 42

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel trellis
Front Suspension43 mm Upside-down non adjustable forks
Rear SuspensionProgressive linkage with fully adjustable Sachs monoshock with piggy back aluminum swing arm
Rake24

Wheels & Brakes

Front Tire Size120/70 – ZR17
Rear Tire Size180/55 – ZR17
Front Brakes2 x 300 mm Discs, 4 piston calipers
Rear BrakesSingle 245 mm disc, 2 piston caliper

Dimension & Weights

Wheelbase56.7 inches / 1440 mm
Fuel Tank Capacity3.6 US gallons / 14.0 L
Dry Weight179 kg / 395 lbs

Features

  • Four stroke engine
  • 90 Lt win cylinder displacement
  • SOHC engine design
  • Desmodromic valve system
  • 2 valves per cylinder
  • Aluminium alloy single-sided trellis swingarm
  • Progressive rear suspension system
  • Adjustable rear ride height
  • 5-spoke wheels
  • Exhaust with double silencer mounted high on the right-hand side
  • Oversized tyres
  • Extra ground clearance
  • Exclusive APTC clutch system
  • Slipper device to prevent rear wheel lock when down shifting
  • Fully exposed engine and bodywork
  • Air-brushed fuel tanks available as customizing option
  • Billet aluminum parts available as customizing option
  • Carbon fibre accessories available as customizing option
