Ducati Monster S2R 800 (2005)

Ducati Monster S2R 800 (2005)

The Ducati Monster S2R 800 is a masterclass in motorcycle design and engineering. Its air-cooled 90-degree V-twin engine, with two valves per cylinder and Marelli fuel injection, delivers a rich and rewarding riding experience.

With its six-speed transmission and supplemental oil cooler, the S2R is perfectly suited for twisty roads where it can shine. The steel trellis frame provides a solid foundation, while the single-sided aluminum swing arm adds a touch of elegance to an already stunning machine.

Climbing aboard, you’re greeted by a tidy instrument cluster and a smooth, effortless startup procedure. Once underway, the Ducati’s 800cc engine springs to life with a sweet, rapid idle that belies its formidable power reserves.

The result is a bike that’s as much a joy to look at as it is to ride. Whether carving through canyons or cruising down the highway, the Ducati Monster S2R 800 is an unforgettable experience that will leave you grinning from ear to ear and begging for more.

Key Specifications

Engine TypeFour stroke, 90 Lt win cylinder, SOHC, desmodromic 2 valves per cylinder.
Engine Capacity803 cc / 49.0 cu in
Max Power56.7 kw / 77 hp
Max Torque73 Nm / 7.4 kgf-m / 54 ft-lbs @ 6500 rpm
Fuel Tank Capacity3.6 US gallons / 14.0 L
Ducati Monster S2R 800 (2005)

All Specifications

Make & Model

ModelDucati Monster S2R 800
Year2005

Engine

Engine TypeFour stroke, 90 Lt win cylinder, SOHC, desmodromic 2 valves per cylinder.
Displacement803 cc / 49.0 cu in
Bore x Stroke88 x 66 mm
Compression Ratio10.5:1
Max Horsepower56.7 kw / 77 hp
Max Torque73 Nm / 7.4 kgf-m / 54 ft-lbs @ 6500 rpm
Engine Management SystemFuel injection, 45 mm throttle body
Cooling SystemAir cooled
Exhaust2-1-2, High

Performance

Top Speed205.8 km/h / 127.9 mph

Transmission

ClutchAPTCwet multiplate with hydraulic control
Gearbox6 Speed
Gear Ratios1st 32/13, 2nd 30/18, 3rd 28/21, 4th 26/23, 5th 22/22, 6th 24/26
Final DriveChain; Front sprocket 15; Rear sprocket 42

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel trellis
Front Suspension43 mm Upside-down non adjustable forks
Rear SuspensionProgressive linkage with fully adjustable Sachs monoshock with piggy back aluminum swing arm
Rake24

Wheels & Brakes

Front Tire Size120/70 – ZR17
Rear Tire Size180/55 – ZR17
Front Brakes2 x 300 mm Discs, 4 piston calipers
Rear BrakesSingle 245 mm disc, 2 piston caliper

Dimension & Weights

Wheelbase56.7 inches / 1440 mm
Fuel Tank Capacity3.6 US gallons / 14.0 L
Dry Weight179 kg / 395 lbs

Features

  • Four stroke engine
  • 90 Lt win cylinder
  • SOHC design
  • Desmodromic valve train with 2 valves per cylinder
  • Marelli fuel injection
  • Supplemental oil cooler
  • Air-cooled engine
  • 90 degree v-twin configuration
  • Six speed transmission
  • Steel trellis frame
  • Aluminum single-sided swing arm
  • High-swept exhaust system
  • Aftermarket Arrow exhaust cans (optional)
  • 5 spoke Marchesini rims
  • White-faced gauges and digital odometer/trip meter
  • Indicator lights
  • Ignition switch with automatic sweep function
  • Choke near the left grip
  • Magura tapered aluminum bars
  • Aluminum foot pegs
