Ducati Monster 750 (1996 – 2001)

Ducati Monster 750 (1996 - 2001)

The Ducati Monster 750 – a true middleweight marvel that bridges the gap between its smaller sibling, the 600, and the larger-than-life 900. Built on an 888-derived frame and SS suspension package, this potent motorcycle boasts a 750SS engine delivering a satisfying power delivery that’s almost as rewarding as its bigger brother.

With a stiff frame and firm suspension, the Monster 750 provides a sporty ride that’s both agile and responsive. Wide handlebars and a low centre of gravity make it an absolute joy to handle, whether navigating tight city streets or carving up twisties on longer trips.

This bike has it all – style, performance, and a dash of eccentricity that sets it apart from the crowd. Its radical styling has created a sensation among riders, with F1 Grand Prix drivers Damon Hill, Michele Alboreto, and Clay Regazzoni among those who’ve fallen under its spell.

The Monster 750 is more than just a motorcycle – it’s an experience that will leave you grinning from ear to ear, eager to hit the road again. With its unique blend of sport and cruiser characteristics, this bike has cemented its place as one of the most desirable rides on the market today.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, SOHC desmodromic 2 valves per cylinder
Engine Capacity748 cc / 45.6 cu in
Max Power47.1 kw / 64 hp
Max Torque60.8 Nm / 6.2 kgf-m / 44.8 ft-lb @ 6850 rpm
Fuel Tank Capacity16.5 L / 4.4 US gal / 3.6 Imp gal
Seat Height30.3 inches / 770 mm
Ducati Monster 750 (1996 - 2001)

All Specifications

Make & Model

ModelDucati Monster 750
Year1996 – 2001

Engine

Engine TypeFour stroke, 90 L twin cylinder, SOHC desmodromic 2 valves per cylinder
Displacement748 cc / 45.6 cu in
Bore x Stroke88 x 61.5 mm
Compression Ratio9.0:1
Max Horsepower47.1 kw / 64 hp
Max Torque60.8 Nm / 6.2 kgf-m / 44.8 ft-lb @ 6850 rpm
Engine Management System2 x 38 mm Mikuni BDST 38 B216A carburetors
Cooling SystemAir cooled

Performance

Top Speed190 km/h / 118 mph

Transmission

ClutchWet, multiplate
Gearbox5 Speed
Primary Drive Ratio1996 – 97: 2.000:1 (31/62)1998 – 01: 1.850:1 (33/61)
Gear Ratios1sr 2.500 / 2nd 1.714 / 3rd 1.333 / 4th 1.074 / 5th 0.966:1
Final DriveChain

Electrical & Electronics System

Battery1996 – 00: 12V 16Ah2001: 12V 10Ah
StarterElectric

Chassis & Suspension

Front Suspension1996 – 99: Inverted type, 40 mm diameter stanchions, Marzocchi2000 – 01:Inverted type, 43 mm diameter stanchions, Showa
Rear SuspensionSachs Boge, progressive linkage with fully adjustable monoshock

Wheels & Brakes

Front Tire Size120/60 – 17
Rear Tire Size160/60 – 17
Front Brakes1996 – 97: Single 320 mm disc, 4 piston caliper1998 – 02:Dual 320 mm discs, 4 piston caliper
Rear BrakesSingle 245 mm disc, 2 piston caliper

Dimension & Weights

Overall Length2080 mm / 81.9 in
Overall Width800 mm / 31.5 in
Overall Height1030 mm / 40.6 in
Seat Height30.3 inches / 770 mm
Wheelbase56.3 inches / 1430 mm
Fuel Tank Capacity16.5 L / 4.4 US gal / 3.6 Imp gal
Dry Weight178 kg / 392 lbs

Features

  • 750SS engine
  • Derived from 888 frame
  • SS suspension package
  • Twin front disc brakes
  • Fuel injection
  • Wide handlebars
  • Low centre of gravity
  • Sporty ride
  • Radical styling
  • Short wheelbase
  • Raised handlebars
  • Lowered foot pegs
  • Multi-tubular trellis frame with gold paint
  • 4.3 gallon fuel tank
  • Removable seat cowl
  • Instrument panel with speedometer and indicators
  • Neutral, turn signals, oil pressure, high beams, battery charge, fuel, and side stand lights
  • Marzocchi upside-down forks with adjustable spring preload
  • Sachs-Boge shock with adjustable spring preload and rebound damping
