Ducati Monster 1100 EVO 20th Anniversary (2013)

Ducati Monster 1100 EVO 20th Anniversary (2013)

The Ducati Monster 1100 EVO 20th Anniversary model marks a milestone in the evolution of the iconic naked bike. Powering this anniversary edition is a 90-degree L-twin engine, delivering 100hp and a distinctive sound that embodies the Monster’s character.

This premium mid-range Monster boasts an array of high-quality components, including Marzocchi front suspension, a revised tail-end, and bold sport-style graphics. The Ducati Safety Pack (DSP) is also standard, featuring ABS and 4-level Ducati Traction Control (DTC).

Riding the Monster 1100 EVO is a truly immersive experience, with its torque-laden engine and refined chassis components working in harmony to deliver agile handling and effortless acceleration.

The result is an unparalleled riding experience that perfectly blends functionality, style, and sport. The 20th Anniversary edition of the Monster 1100EVO is a testament to Ducati’s commitment to innovation and excellence, and it’s clear that this iconic bike will continue to inspire enthusiasts for years to come.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, SOHC, desmodromic 2 valves per cylinder
Engine Capacity1078 cc / 65.8 cu in
Max Power73.5 kw / 100 hp
Max Torque103 Nm / 10.5 / 76 ft-lb kgm @ 6000rpm
Fuel Tank Capacity13 L / 3.4 US gal / 2.9 Imp gal
Weight (Wet/Kerb)414 lbs / 188 kg
Seat Height31.9 inches / 810 mm
Ducati Monster 1100 EVO 20th Anniversary (2013)

All Specifications

Make & Model

ModelDucati Monster 1100 EVO 20th Anniversary
Year2013

Engine

Engine TypeFour stroke, 90 L twin cylinder, SOHC, desmodromic 2 valves per cylinder
Displacement1078 cc / 65.8 cu in
Bore x Stroke98 x 71.5 mm
Compression Ratio11.3:1
Max Horsepower73.5 kw / 100 hp
Max Torque103 Nm / 10.5 / 76 ft-lb kgm @ 6000rpm
Engine Management SystemSiemens electronic fuel injection, 45mm throttle bodies
Lubrication SystemWet sump
Cooling SystemAir cooled
ExhaustLightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminum mufflers

Performance

Top Speed225 km/h / 139.8 mph

Transmission

ClutchWet multiplate with hydraulic control
Gearbox6 Speed
Gear Ratios1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 24/28
Final DriveChain; front sprocket 15; rear sprocket 39

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel Trellis frame
Front SuspensionMarzocchi 43mm fully adjustable usd forks
Front Suspension Travel5.1 inches / 130 mm
Rear SuspensionProgressive with preload and rebound Sachs adjustable monoshock
Rear Suspension Travel5.8 inches / 148 mm
Rake24
Trail86mm / 3.4 in

Wheels & Brakes

Front Wheel/Rim Size10-spoke in light alloy 3.50 x 17
Front Tire Size120/70 – ZR17
Rear Wheel/Rim Size10-spoke in light alloy 5.50 x 17
Rear Tire Size180/55 – ZR17
Front Brakes2 x 320 mm Discs, 4 piston radial caliper with ABS
Rear BrakesSingle 245 mm disc, 2 piston caliperwith ABS

Dimension & Weights

Overall Length2095 mm / 82.5 in
Overall Width784 mm / 30.9 in
Overall Height1099 mm / 43.3 in
Seat Height31.9 inches / 810 mm
Wheelbase57.1 inches / 1450 mm
Fuel Tank Capacity13 L / 3.4 US gal / 2.9 Imp gal
Wet (kerb/curb) Weight414 lbs / 188 kg

Features

  • Four-stroke, 90 L twin cylinder engine
  • SOHC design
  • Desmodromic 2 valves per cylinder
  • Siemens electronic fuel injection
  • 45mm throttle bodies
  • 73.5 kW /100 hp / @ 7500rpm
  • EC Certificate of Conformity: 69.9 kW / 95 hp
  • Trellis frames
  • Chassis components with high attention to user-friendly and safety-conscious detail
  • Torque-laden Desmodromic engines
  • Unmistakable sound and character
  • Entry-level 696 model for new riders
  • Premium mid-range 796 model for experienced riders
  • Monster 1100EVO flagship model with 100hp engine
  • Marzocchi front suspension on 1100EVO
  • Latest generation exhaust system on 1100EVO
  • Refined tail-end design on 1100EVO
  • Bold sport-style graphics on 1100EVO
  • Ducati Safety Pack (DSP) with ABS and DTC on 1100EVO
