Ducati Hypermotard 820 (2014 / 15)

Ducati Hypermotard 820 (2014 / 15)

The Ducati Hypermotard 820 is a testament to Italian engineering, boasting an impressive 110 horsepower Testastretta 11 L-Twin engine that delivers exceptional power and agility.

With its 4 Desmodromically actuated valves per cylinder and Magneti Marelli electronic injection system, this engine is a marvel of modern technology. The addition of ride-by-wire and three Riding Modes – Street, Sport, and Rain – ensures unparalleled control and versatility on the road or track.

The Hypermotard’s Trellis frame, paired with top-of-the-range chassis components, provides an exceptional riding experience that’s both thrilling and practical. Whether carving through twisties or commuting to work, this bike is a masterclass in Ducati’s ability to blend style and substance.

Ducati’s Safety Pack, featuring advanced ABS and Traction Control systems, further enhances the Hypermotard’s capabilities, making it an unbeatable choice for riders who crave excitement without sacrificing safety. With its razor-sharp lines, commanding riding position, and luxurious component quality, the Hypermotard 820 is poised to revolutionize the world of naked bikes once again.

Key Specifications

Engine TypeFour stroke, Testastretta 11 L-Twin, 4 Desmodromically actuated valves per cylinder
Engine Capacity50.1 cubic inches / 821 cc
Max Power80.9 kw / 110 hp
Max Torque89.2 Nm / 9.1kgf-m / 65.8 ft-lb @ 7750 rpm
Fuel Tank Capacity16 L / 4.2 US gal / 3.5 Imp gal
Weight (Wet/Kerb)436 lbs / 198 kg
Seat Height34.2 inches / 870 mm
Ducati Hypermotard 820 (2014 / 15)

All Specifications

Make & Model

ModelDucati Hypermotard 820
Year2014 / 15

Engine

Engine TypeFour stroke, Testastretta 11 L-Twin, 4 Desmodromically actuated valves per cylinder
Displacement50.1 cubic inches / 821 cc
Bore x Stroke88 x 67.5 mm
Compression Ratio12.8:1
Max Horsepower80.9 kw / 110 hp
Max Torque89.2 Nm / 9.1kgf-m / 65.8 ft-lb @ 7750 rpm
Engine Management SystemMagneti Marelli electronic injection, 52mm throttle body, ride-by-wire
Cooling SystemLiquid cooled
Exhaust‘2 in 1 ‘ Exhaust with catalytic converter with twin lambda probe

Performance

Top Speedn/a

Transmission

ClutchAPTC multi-disc wet clutch with control cable
Gearbox6 Speed
Gear Ratios1st 37/15 / 2nd 30/17 / 3rd 28/20 / 4th 26/22 / 5th 24/23 / 6th 23/24
Final DriveChain #530; front sprocket 15; rear sprocket 45

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel Trellis
Front SuspensionKayaba 43 mm upside-down fork
Front Suspension Travel6.7 inches / 170 mm
Rear SuspensionProgressive with adjustable Sachs monoshock.Single-sided swingarm in aluminum
Rear Suspension Travel5.9 inches / 150 mm
Rake25.5
Trail104 mm/ 4.1 in

Wheels & Brakes

Front Wheel/Rim Size10-spoke in light alloy 3.50″ x 17″
Front Tire Size120/70 ZR17
Rear Wheel/Rim Size10-spoke in light alloy 5.50″ x 17″
Rear Tire Size180/55 ZR17
Front Brakes2 x 320 mm Semi-floating discs, Brembo Monobloc M4-32 radially mounted 4-piston calipers with ABS
Rear BrakesSingle245 mm disc, 2-piston caliper with ABS

Dimension & Weights

Seat Height34.2 inches / 870 mm
Wheelbase59.1 inches / 1.500 mm
Fuel Tank Capacity16 L / 4.2 US gal / 3.5 Imp gal
Wet (kerb/curb) Weight436 lbs / 198 kg
Dry Weight175 kg / 386 lbs

Features

  • Four-stroke engine
  • Testastretta 11 L-Twin engine
  • 4 Desmodromically actuated valves per cylinder
  • Magneti Marelli electronic injection
  • 52mm throttle body
  • Ride-by-wire technology
  • 110 HP Testastretta 11 engine
  • Riding Modes: Sport, Touring, and Urban
  • Ducati Safety Pack with ABS and DTC
  • Three-level ABS
  • Eight-level Ducati Traction Control
  • Liquid-cooled engine
  • Improved ergonomics
  • Commanding riding position
  • Adjustable handlebars
  • Footpegs moved forward for comfort
  • 43mm Kayaba usd forks
  • Stroke of 170mm (6.7in)
